WZ30-25 Backhoe Loaders and Excavator

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Model Number:

30-25

Place of Origin:

Shandong, China

Weifang Heng An Imp& Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Model Number 30-25

Place of Origin Shandong, China

Type Backhoe Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 5900*2300*3769

Rated Load 1800KG

backhoe

WZ30-25 backhoe loaders and excavator

	Overall Dimension
1	Length X Width X Height	5900X 2300 X 3769(mm)
2	Cab roof height	2900(mm)
3	Wheel base	2250(mm)
4	Track	1640(mm)
5	Min. ground clearance	300(mm)
	Main Technical Specification
1	system pressure
	load hydraulic system	18Mpa
	dig hydraulic system	20Mpa
	steering hydraulic system	12Mpa

2	system flow	120L/min
3	type	four-wheel drive ,whole hydraulic system
4	total operating weight	7600kg
5	maximum speed	22Km/h
6	maximum gradient capacity	30°

1	loading bucket capacity	1m3
2	rated loading	1800KG
3	maximum articulated height of bucket	3400(mm)
4	bucket discharge height	2795(mm)
5	bucket discharge distance	1048(mm)
6	loading lift capacity	25KN
7	bucket hydraulic translation function	yes
8	bucket lift time	6.8s
9	bucket lower time	2.5s
10	bucket discharge time	1.2s
11	maximum tractive force	39KN
12	maximum breakout force	38KN

1	backacter bucket capacity	0.3m3
2	backacter discharge height	3878(mm)
3	maximum digging depth	4080(mm)
4	maximum digging radius	5688(mm)
5	bucket slewing angle	190°
6	bucket digging capacity	46KN
7	bucket stick digging capacity	31KN
