zl50g Model 5ton wheel loader with shangchai engine for sales

Performance

1

rated load

5000kg

2

overall weight

1710kg

3

rated bucket capacity

3m³

4

maximum tractive force

152KN

5

maximum breakout force

≥170KN

6

maximum grade ability

30°C

7

maximum dump height

3150mm

8

maximum dump reach

1250mm

9

overall dimension (L×W×H)

7920×3050×3400mm

10

minimum turning radius

6640mm

Engine

11

model

Weichai Steyr WD615G.220

12

type

lnline  water cooling dry cylinder  injection

13

No. of cylinder-bore/stroke

6-126×130mm

14

rated power

162kw--2400r/min

15

maximum torque

860N.m

16

min fuel-consume ratio

≤215g/kw.h

Transmission system

17

torque converter

YJ375

18

gearbox mode

Power shift normally engaged straight gear

19

gear shift

4 forward shift  4reverse shift

20

maximum speed

38km/h

Drive axles

21

main reducing spiral

bevel gear grade 1reduction

22

decelerating mode

planetary reduction,grade 1

23

wheel base (mm)

3200mm

24

 wheel tread

2250m

25

minimum ground clearance

450mm

Hydraulic system

26

system working pressure

18MPa

27

 boom lifting time

5.95±0.2s

28

 total time

10.95±0.5s

29

  fuel tank capacity

300L

30

function of leveling automatically

 yes

Brake system

31

 service brake

air over hydraulic disc brake on 4 wheels

32

 parking brake

manual parking brake

Tyre

33

type specification

23.5-25

34

 front tyre pressure

0.4Mpa

35

 rear tyre pressure

0.35Mpa
