Home > Products > semi-automatic block machine > QT5-20 machines for making concrete block/paver China supplier
QT5-20 machines for making concrete block/paver China supplier
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
-
QTJ4-40B hydraform machines for making concrete block China supplier
-
China product 50 tons cement bunker/bin/silo for contruction block machine or electric pole
-
Bamboo pallets used with brick machine to stack cement brick price list
-
Bamboo pallets for stack brick price in Ethiopia Wood pallets for brick machine industrail equipment in Africa
-
Plastic/PVC pallets for brick making machine with long service life in Africa price
-
China best selling product cement silo 50 ton concrete bunker for brick machine/electric pole machine
Product Details
| Condition | New | Type | Paving Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Molding Machine | |
| Method | Hydraulic Pressure | Automatic | Other, Yes, yes | |
| Capacity | 20000 pcs for 200*100*60mm per day, 5500pcs/8h for 400*200*200mm | Place of Origin | Shandong, China | |
| Brand Name | Shengya | Model Number | QT5-20 | |
| Voltage | 380V or more | Power | 22 KW, 22KW | |
| Dimension(L*W*H) | 3650*2100*2720mm | Certification | ISO9001/CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
(1) Advanced hydraulic system and electro-hydraulic integration system is adopted,It is simple in operating and reliable in running
(2) The material distributing system equipped with multirow of stirring forks ,can quickly and evenly discharge the material into the moulding box.
(3) The integration of hydraulic system and vibrating make the brick shaping more quickly and the density of brick is strengthened .
(4) The machine can also produce different sizes of blocks with different moulds.
Specifications:
main machine Power | 22KW |
Cycle | 20S |
Overall Size | 3500X2000X2700mm |
Carriage Size | 1100X550X30mm |
Electrical source | 380V/50Hz |
Total mass | 5000kg |
product quantity | 400*200*200 5pcs/mould 5500pcs/8h 400*150*200 6pcs/mould 6700pcs/8h 200*100*60 20pcs/mold 20000pcs/8h |
Contact : Cassie Sun Mobile: +86-18816786169 (whatsapp/wechat) Skype: cassiebbsun Email: brick20 at
Video website: /watch?v=SJZt2uy3dp0&feature
/watch?v=yt2SyvDNxFM&feature
/watch?v=Sit6TIdzT9M&feature
Concrete mixer JDC350 specifications
feeding capacity | 560L |
discharging capacity | 350L |
productivity | 17-21 M3/H |
speed of stiring shaft | 28R/MIN |
diesel engine power | 15kw |
lifing hopper speed | 20M/min |
pump motor | 0.55 |
Max. diameters of aggregates | 60/40mm |
stiring time | 30-35seconds |
standard height of dischaging | 2200mm |
dimension in transportation state | 2050x2550x2600MM |
weight | 3200KG |
Conveyor belt( 7 meters)
Note: 1.The customer can choose which section he need,so the price is not fixed.
blocks & bricks samples as below:
Warmly welcom to our factory for visiting!!
Quality Guarantee
Our professional engineer would text machine carefully before loading,so please rest assure.
Aftersale Services:
We have established eight oversea offices in Algeria,Cote d'Ivoire,Kenya,Nigeria,Ethiopia,Cameroon,DR Congo and Tanzania.We also have 3 after-service sites aborad :Angola,Sudan,the united Arab Emirates. So we can supply you better and in time service.
Selling is only the beginning of our service,
1,our good after-sale service would provide our customer with both the technology and the skills.
2, our overseas technicians would be there to help installation and teach the using method.
3, we could provide the manual brochure if needed.
