Fluidized Dryer

Fluidized Dryer thumbnail-1
Fluidized Dryer photo-1
US$ 10,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Changgan
Contact Supplier Request Quote Chat Now
Changzhou No. 2 Drying Equipment Factory Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Changgan
Model Number XF
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

XF Series Boiling Drier

Description
Boiling dryer is also call as fluidize-bed. lt consists of air filter, heater, fluidized-bed main machine, feeder, cyclone seperator, cloth bag duster, high-pressure centrifuge fan and operation table. Because the properties of raw material exist difference, when equip the dust removing equipment, it should consider the practical need. It can select cyclone seperator and cloth bag duster at the same time or one of them. In genral speaking, it needs to select cyclone seperator only for raw material that is large in specific gravity and cloth bag duster for powder and small granule raw materials that is light in gravity. Meanwhile there is air feeding device and belt conveyor for seletion.


Separated granule solid raw material is fed into fluidized-bed drier through feeder. Fresh air through filtering and heating is sent to the bottlom of fiuidized-bed by fanand contacts with solid raw material on distributing plate. In this way the fluidized state is formed and the heat exchang between air and solid is carried out. The dried raw material is discharged from outlet and wasted gas is exhausted from the top of fluidized-bed where catches solid powder through cyclone separator, cloth bag duster.
Stream, electricity or hot air furnace can can be used(it can be supplied as request)
It is suitable for drying separated granule such as ,raw material of pharmaceutical industry, tablet, tablet of drink of Chinese traditional medicines; plastic resin, citric acid, other powder and granule of chemical industry, powder of dtink, corn embryo feed of foodstuff industry and so on. The Max diameter of raw material to be dried will 6 mm and the best diameter will be 0.5-3mm.



Features
Automatic production can be realized. It is continous drying equipment. Its features are quick in drying speed ,Iow in drying tempment ,It can guarantee the quality of produtcts and is in conformity with the requirements of GMR

Sketch of structure



Technical parameters

technicalmodel and specifications XFO0.25
-1		 XFO0.25
-2		 XFO0.25
-3		 XFO0.25
-6		 XFO0.3
-2		 XFO0.3
-4		 XFO0.3
-6		 XFO0.3
-8		 XFO0.3
-10		 XFO0.4
-4		 XFO0.4
-6
area of layer(m2) 0.25 0.5 1.0 1.5 0.6 1.2 1.8 2.4 3.0 1.6 2.4
drying capacity (kg h2o/h) 1015 2025 3045 5275 30 4260 6390 84120 105150 5680 84120
power of fan (kw) 5.5 7.5 15 22 7.5 18.5 30 37 48 30 37
temperature of air in () 120140 120140 120140 120140 120140 120140 120140 120140 120140 120140 120140
temperature of air in () 4060 4060 4060 4060 4060 4060 4060 4060 4060 4060 4060
overall dimensions(main machine)L×W×H 1
×0.6
×3.35		 2
×0.6
×3.35		 4
×0.6
×3.35		 6
×0.6
×3.35		 2
×0.7
×3.4		 4
×0.7
×3.4		 6
×0.7
×3.4		 8
×0.7
×3.4		 10
×0.7
×3.4		 4
×1
×3.58		 6
×1
×3.58
occupied area (m2) 18 25 35 40 25 38 45 56 70 18 56
