Boiling Dryer

Boiling Dryer thumbnail-1
Boiling Dryer photo-1
US$ 5,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Fluid Bed Drying Equipment
Place of Origin:
Jiangsu, China
Brand Name:
Changgan, Changgan
Contact Supplier Request Quote Chat Now
Changzhou No. 2 Drying Equipment Factory Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Fluid Bed Drying Equipment
Place of Origin Jiangsu, China
Brand Name Changgan, Changgan
Model Number GFG, GFG
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

GFG Series High-Efficency boiling drying equipment

drying equipment description
Use screw to extrude and vibrate granule and granulate granule with the method of humidity, high speed and mixing;Suitable for drying humidity block or powder raw material in Pharmaceutical, foodstuff, feed, chemical industries and so on fields;The raw material is large in granule and small in block and having adhesive property;



Features
The structure of fluidization bed is of round so as to avoid dead corner;
Inside the hopper there is a stir in order to avoid agglomeration of raw material and forming canal of flow.
The granule is discharged through the method of turning over. In this way it is very convenient and full. The discharging system can be designed as request too;
It is operated at the conditions of negative pressure and seal. The air is filtered.
Therefore it is simple in operation and convenient in clean. It is an ideal equipment that is in conformity with the requirement of GMP;
The drying speed is fast and the temperature is uniform. In general the drying time is 20-30 minutes.



Schmatic of installation



Technical parameters

item model

raw material

 kg 60 100 120 150 200 300 500
fan air volumn m3/h 2361 3488 4000 4901 6032 7800 10800
air pressure mmH2O 594 533 533 679 787 950 950
power kw 7.5 11 15 18.5 22 30 45
stirring power kw 0.55 1.1 1.1 1.1 1.1 1.1 1.1
stirring speed rpm 11
stirring of steam kg/h 141 170 170 240 282 366 451
time of operation min 15-30
hight of main machine square mm 2750 2850 2850 2900 3100 3300 3650
round mm 2700 2900 2900 2900 3100 3600 3850
