Wheel Loader 936

Wheel Loader 936 thumbnail-1
Wheel Loader 936 photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
HHM
Model Number:
936
Contact Supplier Request Quote Chat Now
Weifang Huahai Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao CHina
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name HHM
Model Number 936
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 7100mm x 2510mm x 3170mm
Rated Load 3000kgs

Specifications

Powerful engine;
Hydrauic transmission;
4WD,articulated structure;
Multi-purpose implements;
Optional quick hitch, joystick.

Wheel loader 936

Operating weight:10700kg

Rated load: 3000kg

Bucket capacity: 1.8cu.m

Tread:1865mm

Wheel base: 2850mm

Max. traction force: 10707kgf

Max. breakout force: 9789kgf

Min. turning radius outside bucket:5912mm

Min. turning radius outside tire:5381mm

Min. ground clearance:370mm

Max. dump height(-45degree):2950mm

Min. dump reach:1050mm

Max. gradeablity:30 degree

Overall dimension:7100mm x 2510mm x 3170mm

Engine: Deutz, Vertical,6-Cylinder in line, Water Cooled and 4-stroke, direct injection

92kw/125hp, 2200r/min, Max torque 436N.m

Transmission: hydraulic torque converter, power shift gearbox ,2 forward + 1 reverse

Travel Speed: Forward 1st gear 0~13km/h , 2nd gear 0~38km/h

           Reverse 1st gear 0~17km/h

Steering: articulated full-hydraulic steering system, Max. turning 38degree each side

Axles: 4WD, front rigid axle, rear axle oscillating mounted on rear chassis

Tire:17.5-25

Hydraulic system: hydraulic gear pump, single lever hydraulic pilot control of arm

lifting and bucket turning, double acting hydraulic cylinder,

hydraulic pressure 2320psi(16Mpa)

Brake system: service brake is air over hydraulic disk brake,

park brake is air operated external disk brake

Electric system: traffic lights, working lights, rotary warning light, rain wiper, radio,

 oil pressure meter, hour meter, fuel meter, cabin fan, electric key start

Cabin with heater system, air suspension seat, fire extinguisher, safety hammer, adjustable dashboard



Standard equipment:

Deutz TD226B 6-Cylinder diesel engine;2 speed power shift transmission; Luxury cabin with heater; single lever hydraulic pilot control;1.8cu.m bucket with teeth; 17.5-25 tire.



Optional equipment:

4 forward + 2 reverse power shift gearbox;

Luxury cabin with air conditioning;

Hydraulic quick hitch system for fast change implements;

hydraulic 3rd function;

20.5-25 tire;



Optional implements :

4in1 bucket,

range of light material buckets from 1cu.m to 3cu.m,

rock bucket,

pallet fork & gripper,

log gripper, hay & silage handling attachment.

Wheel Loader 936Wheel Loader 936Wheel Loader 936Wheel Loader 936
