Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Loader > 5T Wheel Loader ZL50F

5T Wheel Loader ZL50F

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Brand Name:

Model Number:

ZL50

Contact Supplier Request Quote Chat Now

Weifang Huahai Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Brand Name ZL

Model Number ZL50

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 7934mm x 3066mm x 3410mm

Rated Load 5000kg

Specifications

reasonable price and good quality;
optional setup like engine, gearbox and hydraulic;
optional implements;

wheel loader ZL50F

Operating weight:17000kg

Rated load:5000kg

Bucket capacity: 3.0cu.m

Tread:2250mm

Wheel base:3200mm

Min. turning radius outside bucket:5623mm

Min. turning radius outside of tire:4857mm

Min. ground clearance:450mm

Max. dump height:3145mm

Min. dump reach:1222mm

Max. gradeablity:30 degree

Overall dimension: 7934mm x 3066mm x 3410mm

Engine: Weichai Diesel, Vertical, in-line 6-Cylinder,Water Cooled and 4-stroke,

162kw/220hp, 2200r/min

Transmission: hydraulic torque converter, power shift gearbox ,4 forward + 4 reverse

Travel Speed:1st gear 8.9km/h,2nd gear 16.5km/h,3rd gear 25.5km/h, 4th gear 44.5km/h

Steering: articulated hydraulic steering system, Max. turning 38degree each side

Axles: 4WD, front rigid axle, rear axle oscillating mounted on rear chassis

Tire:23.5-25

Hydraulic system: hydraulic gear pump, 2 lever mechanical control of arm lifting and

bucket turning, double acting hydraulic cylinder,

hydraulic pressure 2320psi(16Mpa)

Brake system: service brake is air over hydraulic disk brake,

park brake is air operated external disk brake

Electric system: traffic lights, working lights, rotary warning light, rain wiper, radio,

oil pressure meter, hour meter, fuel meter, cabin fan, electric start

Cabin with heater system, air suspension seat, fire extinguisher, safety hammer, adjustable dashboard

Standard equipment: Weichai WD615G-220 6-Cylinder engine;4 speed power shift transmission; Cabin with heater; 2 lever mechanical control; General bucket or heavy duty bucket; 23.5-25 tire.

Optional :

Shangchai C6121 engine (Licensed caterpillar 3300);

Advanced ZF WG180 transmission 4 forward + 3 reverse, electronic gearshift lever; Cabin with air conditioning;

Hydraulic quick hitch system for fast change implements;

One lever hydraulic pilot control(joystick);

hydraulic 3rd function;

Implements :

Rock bucket, range of light material buckets from 3cu.m to 4.5cu.m, coal bucket, pallet fork & grab fork, log gripper, hay & silage handling attachment.
