3T Wheel Loader

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

SAM

Model Number:

SAM836

Weifang Huahai Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qindao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name SAM

Model Number SAM836

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 6890X2430X3070MM

Rated Load 3000KGS

Specifications

wheel loader,wheel loaders
bucket capacity 1.7-2.5cbm
max dump height 3100mm
max breakout force 127KN
max traction force 95K

3T wheel loader

1. The big loading engine side covers made in steel are of good appearance and suitable for maintenance

2.Pilot hydraulic implement controls make operate easy and comfortable

3, Central articulated frame, small turning radius, mobile and flexible, lateral stability, ease of operation in the narrow

space.

1	rated loading	3000kg
2	overall weight	9600kg
3	bucket capacity	1.7-2.5m3
4	maximum traction force	95KN
5	maximum breakout force	127KN
6	maximum grade ability	30°C
7	maximum dump height	3100mm
8	maximum dump reach	1006mm
9	overall dimension (L×W×H)	689024303070mm
10	minimum turning radius	5097mm
11	model	YC6B125G-T20 / Duetz TD226B
12	type	Vertical, in-line, water cooled, 4-stroke diesel engine
13	NO. of cylinder-bore*stroke	6-108*125
14	rated power	92kw—2200r/min
15	maximum torque	500N.m
16	min. fuel-consume ratio	<=210Kw h
17	torque converter	YJ315-X
18	gearbox mode	Power shaft normally engaged straight gear
19	gears	4 forward 2 reverse
20	maximum speed	40km/h
21	main reducing spiral	bevel gear grade 1reduction
22	decelerating mode	Planetary reduction grade 1
23	wheel base (mm)	2660mm
24	wheel tread	1800mm
25	ground clearance	400mm
