YD-3500 PET Blow Molding Machine
- ningbo
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | YUANDA | Model Number | YD-3500 |
Product Description
YD-3500 PET blow molding machine
A.Brief Introduction
YUANDA series are the most stable two-step fully-automatic pet stretch-blow moulding machines(preheat). It has two to eight cavities and the maximum capacity of the products is 2L. It can blow bottles in shapes: carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of plastic of crystalline type, such as PET and PP etc.
D. Technical Parameter:
ITEM | YD-1800 | YD-3500 | YD-5500 | YD-8000 |
Theoretical output | 2000 | 4000 | 6000 | 8000 |
ntainer volume | 2L | 2L | 2L | 2L |
Max.neck diameter | 38MM | 38MM | 38MM | 38MM |
ntainer diameter | 120MM | 120MM | 120MM | 120MM |
ntainer height | 335MM | 320MM | 250MM | 250MM |
Number of cavity | 2 | 4 | 6 | 8 |
Number of lamp | 24 | 24 | 24 | 48 |
Max.heating power | 50KW | 84KW | 90KW | 90KW |
Installation power | 110KW | 95KW | 100KW | 100KW |
Actual power consumption | 45KW | 40KW | 50KW | 50KW |
Operatating low pressure | 0.7-1.0Mpa | 0.7-1.0Mpa | 0.8-1.0Mpa | 0.8-1.0Mpa |
Low pressure consuming | 2000L/min | 2000L/min | 2000L/min | 2000L/min |
Blowing pressure | 2.5-3.5Mpa | 2.5-3.5Mpa | 2.5-3.5Mpa | 2.5-3.5Mpa |
High pressure consuming | 5500L/min | 5000L/min | 2.8~3.5m3/min | 3.5~5.0m3/min |
Operating pressure | 0.3-0.5Mpa | 0.3-0.5Mpa | 0.3-0.5Mpa | 0.3-0.5Mpa |
Temperatuer | 10 degree | 10 degree | -10°C~55°C | -10°C~55°C |
Flow rater | 40 L/min | 40 L/min | 50L/min | 70L/min |
Machine dimension | 2.25×1.5×2.2 | 3.55×1.5×2.2 | 4.25×1.5×2.2 | 4.5×2.25×2.2 |
Machine weight | 4200Kg | 4800Kg | 5000Kg | 5000Kg |
