Specially for PET Bottle Blowing High-pressure Air Compressor
USD $4,800 - $5,800
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- ningbo
- T/T
You May Like
Product Details
Type: | Piston | Configuration: | Stationary | Power Source: | AC Power |
Lubrication Style: | Lubricated | Mute: | No | Place of Origin: | Jiangsu, China |
Brand Name: | SHANGAI | Model Number: | 2.4/30 |
Product Description
Specially for PET Bottle Blowing High-pressure Air Compressor
Discharge capacity: 2.0-2.4m3/min
Discharge pressure: 30Bar
Model No. | Air Discharge (m3/min) | DischargePressure (Mpa) | Motor Power (kw) | Weight (kg) | Size (mm) Length×width×height |
2-09WM-1130 | 2.0 | 3.0 | 11×2 | 1050 | 1900×1700×950 |
2-09WM-1130H | 2.4 | 3.0 | 11×2 | 1090 | 1900×1700×950 |
2-09WM-1530 | 2.4 | 3.0 | 15×2 | 1150 | 1900×1700×950 |
Main Characters of Shangair Brand Specially for PET Bottle Blowing High-pressure Air Compressor:
- Low exhaust temperature (when exhaust pressure is 7.0 Mpa, exhaust temperature is equal to or less than 170; aftercooler-processed temperature at outlet is only 15 to 20 higher than ambient temperature) and oil consumption is low (oil consumption is less than 2.6g/h).
- Advanced Shangair patented direct-flow valve technology is used for low pressure air compressor, which increases air output by 13% and reduces energy consumption by 11%.
- Ring valve made from Sweden stainless steel strip is used for high pressure air compressor.
- In order to ensure safety and reliability of air compressor, redundancy design principle is applied and multiple protection measures are taken; overload protection; overheat protection; phase-failure protection; undervoltage protection; drain and exhaust when unloading and stopping running the equipment; ensure zero-pressure start; ensure interstage timed drainage when air compressor operates continuously, which effectively prevents water flood and liquid impact.
- There are interstage safety valve and pressure indicator; pressure and temperature measuring interface is available; it is convenient for user to install and debug remote monitoring system.
- Use Shangair patented multi-stage complex impedance suction filter featuring low noise and pollution resistance.
- Advanced inductive low oil level alarm (or forced stoppage) device featuring stable performance and reliability and ensuring that the compressor is free from oil shortage and burn-in failure.
- 5-digit digital counter recording accumulated operation hours of the compressor.
- Service life of plated piston ring is three to four times longer.
- Completely new dynamic balancing design; vibration severity is only one fourth of the internationally advanced level
