Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > SD/HD/3G-SDI Video Fiber Optic Eetender PW-STF5804H

SD/HD/3G-SDI Video Fiber Optic Eetender PW-STF5804H

Name: SD/HD/3G-SDI Video Fiber Optic Eetender PW-STF5804H
Brand: Pway
SKU: 135022041
Availability: InStock

SD/HD/3G-SDI Video Fiber Optic Eetender PW-STF5804H thumbnail-1

SD/HD/3G-SDI Video Fiber Optic Eetender PW-STF5804H photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Pway

Model Number:

STF5804H

Contact Supplier Request Quote Chat Now

Shenzhen City Pin Wei Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Pway

Model Number STF5804H

Product Description

Features

Support 4/8 channel SD/HD/3G-SDI video embedded audio signal via fiber
SD,HD auto-detection, supported transmission rate from 270M bit/s to 1.485G bit/s
Transmission distance is from 0km to 60KM via multimode fiber or single mode fiber.
Support SMPTE 259M (1.485Gbps),SMPTE 259M (270Mbps) and DVB-ASI
With 2CH Bi-Di data
Operation status indication by LED

STF5804H SDI Fiber Optic

Model/Name	PW-STF5804H
Quantity/Type	Single Mode, Single Fiber
Video port	4CH BNC SD/HD-SDI	8CH BNC SD/HD-SDI
Transmission Distance	0m-20Km/40km/60KM optional
Fiber Connector	FC
Wave Length	1310nm/1550nm
Transmitted power	-10dbm~-3dbm <-34dbm
MaximumReceiving Sensitivity	<-34dbm
Signal Type	SD-SDI(270Mbps)/HD-SDI(1.485Gbps)
Support Input Format	SD: 525i @ 59.94Hz, 625i @ 50Hz HD: 720p @25Hz /29.97Hz /30Hz 720p @ 50Hz / 59.94Hz / 60Hz 1080i @ 50Hz / 59.94Hz / 60Hz 1080p @23.98Hz/24Hz/25Hz/29Hz/30Hz
Video Standard	SMPTE 292M,SMPTE 259M
DATA comm. method	2CH RS-485/Half duplex/ Industrial terminals
In-out electrical level	800mVp-p±10%
In-0ut Ohm	75Ohm
Digital Audio	48KHz
AES digital audio channel	8CH
Power Supply	AC110V/220V
Power Consumption	3~5Watts
Operating Temperature	0°C ~ 60°C /32°F ~ 140°F
Storage Temperature	-30°C ~ 70°C / -22°F ~158°F
Relative Humidity	20~90% RH (Non-condensation)
Dimension	48016243mm/18.96.381.69in
Weight	2880g(Tx and Rx)		2950g(Tx and Rx)

Instructions for use

Application Diagram

Company Information

____________ Factory Advantage ____________

	Introduction Shenzhen Pinwei Technology Co., Ltd. is a company engaged in wireless video production accessories manufacturers, the company is located in Shenzhen Baoan Longhua Sea Star Technology park.
Strong sales team We have laptop parts export experience more than 10 year.Excellent team and perfect after service make our business is an enjoyment.
	Production equipment Maintenance of factory production lines and equipment regular maintenance, make more smooth, the equipment will be worn down to the minimum.
Production line Professional production lines and improve the process, prompted us to constantly improve the quality of products and delivery efficiency, I will continue to strive to improve in.
	Factory warehouse In cooperation with a number of companies, to ensure the timeliness of goods,The strict professional warehouse system to make our warehouse colleaguesarrangement efficiency and safety of goods transport.

After-sales service

If customer find quality problems within 15 days after received merchandise, please note us , we will pay highly attention to this matter, we will communicate with customer to confirm the issue is caused by man-made or products. Then we will make solution with relevant department and feedback to customer on time.

Customer service

your inquiry or questions will be reply within 24 hours except holidays in China. and you can talk with our online sales on our webpage or find us on Skype, Alibaba TM , MSN etc for a fast communication.

About shipping

DHL , UPS , TNT , Fedex : Process time + shipping time take 2-6 days to most of countries if without custom clearance problem , but might meet custom duty . Shiping by DHL, EMS, FEDEX, UPS , TNT , AIR CARGO, SEA CARGO, CONTAINER etc according to specific order with standard packaging.
