Microwave Thawing Equipment System

Specifications

The microwave thawing is used for the meat defrosting, sterilizing which can meet  requirements for a 200kg per batch for

25kW-915MHz Microwave Frozen Meat Block Thawing Conveyer System

1.This conveyer type system consists of following parts

1) An adjustable 25kW/915MHz microwave power source with 25kW/915MHz magnetron, standard WR975 waveguide launcher, conventional transformer power supply controlled by electromagnetic current to adjust output power from 5-25kW.

2) Microwave transiting system consisting of WR975 circulator, dummy load, which can not only ensure the power source working stable but get much more uniform defrosting result.

3) Microwave cabinetsWith CAD designed size of 3.2 (L) x 0.9(W) x 0.6H(m) , proper microwave feeding ways and power adjustment, three proper air cooling fans furnished on the back of cabinet section for moisture removing, it offers good heating uniformity, the optimum defrosting result and finally can meet  requirements for a 200kg per batch for thawing frozen meat blocks (at -15deg.C) to -2deg.C. The final quantity of production for the meat block dimensions as 580 (W) x 390(D) x 160(H(mm), weight between 25-27kg, can reach about 1.5-2.0 tons per hour;Microwave Thawing Equipment for Frozen Pork

4) The input and output leakage controlling sections with sizes of 1.5 (L) x 0.9(W) x 0.22(H)(m) and two cabinet doors with the sizes of 0.8 (L) x 0.5(W) x 0.3(H)(m) and good stroke design ensures microwave leakage safety and convenient operation.

5) The total length of the system is about 8m. A good designed Teflon conveyer line system with two frozen meat blocks put on in series and the speed control at about 0.1-0.5 meter per minute, the quantity of production can reach about 0.7-1.0 tons per hour.

6) Stainless materials can meet all food processing standards;

2. Microwave Thawing Equipment Main specifications

1) Main power supply:           380VAC±5%, 60Hz.

3 phases and 4 lines, 50KVA

2) Power consumption:         40KVA

3) Microwave frequency:       915MHz±25MHz

4) Microwave power output:  0 - 25KW continuous adjustable

5) Waveguide interface:        WR975

6) Microwave leakage: <5mW/cm²  (International standard)

7) Cooling water:           &ge;12L/min, 0.3Mpa (flow pressure),

                                      &le; 22 (water inlet temperature)

8) Conveyer speed:        0 ~ 1 m/min

9) Temperature measure range:   -20 ~ 350 infrared sensor

10) Defrosting temperature:          -15 to -2

11) Processing Output:   About 700-1000 kg/h

12) Main dimensions:

(1) Door opening size:    640 x 390 mm

(2) Filter opening size:    900 x 30 mm

(3) Conveyer belt:           830(W) x 16500(L) mm

(4) Control Cabinet:        1250 x 1000 x 2150 mm.

(5) Framework:               8200 x 1200 x 1600 mm;
