Help CenterUsed Metal Perforating Machine
Related Products
-
Barbed Wire Making MachineUS$ 2,000 - 8,000MOQ: 1 Set -
Hexagonal Wire Netting MachineUS$ 4,500 - 10,000MOQ: 1 Set
-
High Quality Hexagonal Wire Mesh MachineUS$ 3,000 - 6,000MOQ: 1 Set
-
Sheet Metal Punching MachineUS$ 3,000 - 15,000MOQ: 1 Set
-
Sheet Metal Perforating MachineUS$ 3,000 - 15,000MOQ: 1 Set
Specifications
1.Pounding thickness:2-5mm2.Pounding plate:1.22*2.44m
3.Voltage:380V 50HZ
4.power:7.5kw
sheet metal perforating machine
Expanded metal machine is used to produce various expanded metal mesh for different uses. Contact us for more information.
Expanded filter mesh is used as the inner or outer core of air filter.
A) Max. width: 1000mm
Metal sheet thickness available: 0.2 - 1mm
Frequency: 150/min.
Metal sheet feeding: 0 - 1.2mm
Max. length of mesh: 25mm
Motor power: 3KW
Measurement: 1740 x 1400 x 1500mm
Weight: 2000KG
B) Max. width: 1250mm
Metal sheet thickness available: 0.3 – 1.5mm
Frequency: 150/min.
Metal sheet feeding: 0 - 1.2mm
Max. length of mesh: 30mm
Motor power: 4KW
Measurement: 1940 x 1600 x 2010mm
Weight: 3000KG
Type |
ZCX-A20 |
ZCX-B10 |
ZCX-150 |
ZCX-300 |
Max.Thickness |
1.0 mm |
1.0 mm |
1.0 mm |
1.0 mm |
Width |
500 mm |
500 mm |
1000 mm |
1000 mm |
Stroke Per Minute |
180/min |
200-400/min |
150/min |
300/min |
Distance of Feed |
0-1.2 mm |
0-1.6 mm |
0-1.2 mm |
0-4 mm |
Max. LWD of Mesh |
20 mm |
10 mm |
25 mm |
25 mm |
Motor |
2.2 KW |
2.2 KW |
3 KW |
5.5 KW |
Weight |
950 Kg |
950 Kg |
2000 Kg |
2050 Kg |
Measurement (mm) |
1090x710x1450 |
1090x710x1450 |
1800x1320x1550 |
1470x850x 1630 |
Type |
ZCX-150 |
ZCX-2.5 |
ZCX-4.0 |
ZCX-8.0 |
Max.Thickness |
1.25 mm |
0.5---2.5 mm |
0.5---4 mm |
8 mm |
Width |
1250 mm |
2000 mm |
2000 mm |
2000 mm |
Stroke Per Minute |
150/min |
70/min |
60/min |
45/min |
Distance of Feed |
0-2 mm |
0-4 mm |
0-4 mm |
0-7 mm |
Max. LWD of Mesh |
30 mm |
100 mm |
150 mm |
160 mm |
Moto |
4 KW |
11 KW |
15 KW |
30 KW |
Weight |
3000 Kg |
11000 Kg |
12000 Kg |
21000 Kg |
Measurement (mm) |
1940x1600 |
2400X3500 |
3600x2500 |
3000x3200 |
