Screw oil press working principle
1. When oil press is on work , material enter the extruding chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed.
2. Under the high temperature condition in the chamber , there is quite strong friction among press screw , chamber and the oil material.
3. On the other hand , root diameter of the pressing screw carries larger from one end of the other.
4. Hence when rotation ,the thread not only pushed particles moving forwards but also turns them outward as well.
5. Meanwhile , particles adjacent the screw will rotate along with screw’s rotating,causing every particle inside the chamber to possess different speed.
Therefore , relative movement among particles creates neat which is necessary during manufacturing because of helping protein change property, damage colloid,increase plasticity, decrease oil’s elasticity, resulting in high oil.
6YL Series Product Technical Data
|
6LYL-120 |
6YL-140 |
6YL-160 |
|
Speed of press screw |
30-45r/m |
28-40r/m |
28-40r/m |
|
Gear ratio of gear case |
14/42×19/57=1:6.63 |
15/38×19/48=1:7.38 |
15/38×15/52=1:8.78 |
|
Boundary dimension |
1650×1150×1750 |
2200×1600×2150 |
2500×1600×2500 |
|
Handling capacity |
80-150Kg/H |
250-400Kg/H |
400-600Kg/H |
|
Weight |
760Kg |
1300Kg |
2000Kg |
|
Power |
Main engine |
Y160L-6-5.5kW |
Y180L-6-15Kw |
Y200L-6-18.5Kw |
Vacuum pump |
Y90S-4-0.55Kw |
Y100L1-4-2.2Kw |
Y100L1-4-2.2Kw |
|
Heater |
2Kw |
3.8Kw |
4Kw |
|
