YT-R3 Metal Sheet Roll Forming Machine

Hangzhou Yutong Machinery Co., Ltd.
YT-R3 Metal Sheet Roll Forming Machine thumbnail-1
YT-R3 Metal Sheet Roll Forming Machine thumbnail-2
YT-R3 Metal Sheet Roll Forming Machine thumbnail-3
YT-R3 Metal Sheet Roll Forming Machine thumbnail-4
YT-R3 Metal Sheet Roll Forming Machine thumbnail-5
YT-R3 Metal Sheet Roll Forming Machine photo-1
YT-R3 Metal Sheet Roll Forming Machine photo-2
YT-R3 Metal Sheet Roll Forming Machine photo-3
YT-R3 Metal Sheet Roll Forming Machine photo-4
YT-R3 Metal Sheet Roll Forming Machine photo-5
US$ 1 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Yutong
Model Number:
YT-R3
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Yutong
Model Number YT-R3
After-sales Service Provided Engineers available to service machinery overseas

YT-R3 metal sheet roll forming machine

1). It can produce many types of C-shaped purline.
2). Material Thinckness:1.8mm-3.0 mm

1. Components for the Machine

The purline forming machine includes in automatic hydraulic decoiler, sheet leveling equipment, roll forming system, punching equipment, post-cutting equipment, hydraulic station, electric controlling system and supporter for purline.

2. Main technical Parameters

Item

Specification



Material

Type

chromed coils

Thickness(mm)

1.8-3

Yield strength(mpa)

235

Roller material

Cr12 mould steel

Forming speed(m/min)

10-15

Output speed(m/min)

12-15

Speed adjusting mode

AC Frequency

Roller drive

Decelerating motor + Chain drive

Cutting mode

Hydraulic cutting

Cutter material

Cr12 mould steel

Length measurement

Encoder

Control mode

Mitsubishi PLC

Operating mode

Button + Mitsubishi Touch screen

Main motor power(kw)

15KW

Total power(kw)

20.5KW

3.Pictures

 YT-R3 metal sheet roll forming machineYT-R3 metal sheet roll forming machineYT-R3 metal sheet roll forming machineYT-R3 metal sheet roll forming machine

4. Process flow:

Decoiler -- Feeding & Guiding – Leveling--Punching--Roll forming---Hydraulic Cutting – product to run out table 4. Process flow:

5.Packaging

1.One 40ft container for one machine with mechanical decoiler;

2.Main machine body and decoiler is load naked (tighten to container with steel wire rope)

3.PLC cabinet be packaged by PLYWOOD

4.Some spare parts and tools are loading in tooling box.

   Delivery Detail: 45 days after receiving deposit

If you have any question pls let us know when you feel free, thank you!
