gold and silver melting furnace,tin melting furnace

Introduction and application

        Medium Frequency Induction Furnace is the device converting three phase power current into single-phase intermediate frequency current and enabling metal to produce eddy current loss through the electromagnetic field induction to achieve heating and melting. Mainly be used in the material of ferrous and non-ferrous metal casting, melting and heating treatment industry, such as iron, steel, brass, cooper ,zinc ,tin and so on. As well as heating treatment prior to forging, sintering and tube-bending forming in casting and melting industries.

Performance Characteristics:

1.Zero-voltage scanning soft , available for start or stop at any time under any state without impact on power supply;

2.Speedy melting, low production cost , low pollution, conforming to environmental protection requirement;

3.Melting directly from low temperature, available for fully emptying of solution , easy change of category of melting material;

4.Flexibly adjustable power, easy and continuous smooth adjustment, easily controllable temperature, low oxidization loss, uniform metal content;

5.Furnace shell with cast aluminum ally or steel shell construction, small footprint, easy overturn body, available for selection of electric, manual, hydraulic or other overturn mode as needed;

6.Contravariant automatic regulation circuit available for matching of load impendence automatically, maintaining good operation without regulation or compensation of capacitance; power supply with fault diagnosis facilitating service.

Equipment Type & Technical Parameters:

Remark:

Melting time and power  consumption/ton is important to equipment power, raw material shape and weight, operator's skill level and other elements

Standard Device configuration:

1.An intermediate frequency power supply ,

2.a capacitor,

3.a tilting control box ,

4.an intermediate frequency body,

5.a reducer box ,

6.two sets of supports and water-cooled cable

Enterprise Certification:

Own has import and export goods declaration shipper registration certificate

All products are reached international exported level, and has passed CE and ISO9001:2000 certificate.

Technical and After-Service

We provide not only excellent equipments but also perfect after-sale service as below:

1. We also provide customized. Can custom made non-standard products with different power and smelt time according customer requirement.

2. All favorable price will to provide various spare parts depend on your order/

3. Moreover, we are kindly help customer to installing and testing the equipment, and provide the install and operate illustrated books .

4. Free technical training , technical consult

5. Provide long-term technical services and follow-up service.

6. Product quality guarantee period for a yea after buy equipment.
