RDS-10 Ammonia cracker for atmosphere protective
Ammonia Generator Technology:
The ammonia decomposition furnace is composed of liquid ammonia as raw materials, through catalytic pyrolysis to get 75% hydrogen and 25%nitrogen mixture gas. The chemical equation as below :
2NH3= 3H2 + N2
Ammonia cracker of chemical reaction that under normal conditions, 1000 Moore ammonia gas complete decomposition can produce hydrogen nitrogen mixturegas 44.8 Nm3, and absorption heat 11040 Kcol, namely 1 kg liquid ammonia complete decomposition can produce 2.64 m3 hydrogen nitrogen mixturegas, according to the chemical reaction formula, ammonia decomposition gas from 75% H2 and 25%N2. To make ammonia get fully decomposition, must meet the following conditions:
1, timely and sufficient supply a great deal of heat.
2, good catalyst.
3, liquid ammonia for the purity of more than 99.8% (national standard level industrial ammonia).
Characteristics :
1, This series of ammonia cracker has simple structure, convenient operation, less investment, high efficiency, etc.
2, Gas circuit with good sealing, without ammonia smell when production , will not affect the operating environment.
3, high purity of decomposition gases can be used to the demand is higher condition, the additional purification device can obtain more satisfactory protective gas.
4, The catalyst activity is higher, decomposition effect is good, the life of not less than two yearsunder normal working condition.
Application of Ammonia Cracker :
Ammonia cracker gas has more and more be used because of easy to be get and lowest cost , it mainly be used for as below:
1.1. Metal material bright heat treatment , such as , stainless steel belt, silicon steel sheet , precision alloy, brass band and ordinary strip bright heat treatment , etc.
1.2. Metal reduction : tungsten molybdenum reduction , iron power reduction of reducing atmosphere;
1.3. The reduction of power metallurgy sintering and so on .
1.4. The mechanical part’s bright ,quenching,especially suitable for high speed steel , bearing steel , etc
| Model Type | Power (KW) |
Voltage (V) |
Rated gas production rate (M3/h) |
Liquid Ammonia Consumption (kg/h) |
Working Temperature(℃) |
Catalyst | cooling water consumption (T/h) |
| RDS-5 | 5 | 380 | 5 | 2 | 600~650 | Nickel catalyst | / |
| RDS-10 | 12 | 380 | 10 | 4 | 800~850 | Nickel catalyst | 0.5 |
| RDS-20 | 24 | 380 | 20 | 8 | 800~850 | Nickel catalyst | 1 |
| RDS-30 | 36 | 380 | 30 | 12 | 800~850 | Nickel catalyst | 1 |
| RDS-50 | 60 | 380 | 50 | 20 | 800~850 | Nickel catalyst | 2 |
| RDS-100 | 110 | 380 | 100 | 39 | 800~850 | Nickel catalyst | 4 |
| RDS-200 | 210 | 380 | 200 | 77 | 800~850 | Nickel catalyst | 6 |
| RDS-300 | 390 | 380 | 300 | 116 | 800~850 | Nickel catalyst | 9 |
| RDS-400 | 470 | 380 | 400 | 154 | 800~850 | Nickel catalyst | 12 |
| RDS-500 | 550 | 380 | 500 | 193 | 800~850 | Nickel catalyst | 15 |
Foshan RongDongsheng Furnace Industry Co.,Ltd. was founded in 1997 in Foshan , Guang dong Province of China , Covering more than 10000 M2 and very closed to Guangzhou city
Our company has passed ISO9001 international management system certification and European CE certificate.
With many years experiences in R&D and manufacturing, wide learning and absorbing from others, continuous summarization and innovation, as well as advanced manufacturing equipments and first-class technicians, we set up our branch company at Shun de City of Guan dong province in 1999.
