Batch bottom high shear mixer
Model ESSD
Description
ESSD batch high shear mixer offers a full range of mixer for production scale. The mixer is amounted at the bottom of the vessel to leave more space on the top of the vessel to apply different functions. Each mixer, with its precision-engineered rotor/stator workhead, far outperforms improving quality, product consistency and process efficiency.
Features
Capacity
100 - 15,000 litres.
Workheads
Speical designed workheads available for different applications
Materials of Construction
Product contact in SS304 or 316L stainless steel.
Motor Specification
1-75 kW, TEFC, flame proof, ATEX approved and stainless steel motors available as standard.
Mounting
All mixers can be mounted on the bottom of the vessel
Sealing
Single or double mechanical shaft seals can be supplied according to the working process.
Cleaning
Simple, easy-to-clean construction.
Main Technical Data
Type |
Power (KW) |
Speed (rpm) |
Capacity (L) |
|
ESSD 100 |
2.2 |
3000 |
10-50 |
|
ESSD 200 |
4.0 |
3000 |
30-200 |
|
ESSD 500 |
7.5 |
3000 |
50-500 |
|
ESSD 1000 |
11 |
3000 |
100-1000 |
|
ESSD 1500 |
15 |
3000 |
100-1500 |
|
ESSD 2000 |
18.5 |
1500 |
200-2000 |
|
ESSD 2500 |
22 |
1500 |
300-2500 |
|
ESSD 4000 |
37 |
1500 |
800-4000 |
|
ESSD 8000 |
55 |
1000 |
1500-8000 |
|
ESSD 15000 |
75 |
1000 |
2500-15000 |
|
