Home > Products > High Shear Mixer > Pneumatic High Speed Disperser
Pneumatic High Speed Disperser
- 50 Set / Sets per Month
- Shanghai
- T/T Credit Card
Product Details
Condition: | New | Mixer Type: | Agitator | Product Type: | Paint |
Application: | Liquid with Suspended Solids | Additional Capabilities: | Coating | Place of Origin: | Shanghai, China |
Brand Name: | ESPREAD | Model Number: | ESSQ | Voltage: | 380V/220V/440V/460V Customized |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Pneumatic High Speed Disperser
Model:ESFSA
Description
Industrial high speed disperser ESFSA is a typical production chemical equipment to pre-mix or mix solid/liquid liquid/liquid phase. It used for as stirrer, blend, disperser and mix paint, ink and pigments dispersion and others.
Feature
Main shaft and dispersing disc
A SS 304 shaft duly machined and balanced is provided with a cowless disperser blade of special design for quick and efficient dispersion. The disperser’s blade is made from special steel to withstand high wear and tear. The shaft is installed in a bearing housing provided with taper roller bearings. Lubrication points are provided on the housing.
Lifting and lowering
The entire shaft is drived by pneumatic pump lifting system.
Electric Motor
TEFC motor, drives a set of pulleys and V belts. The Motor is provided with a belt tensioning device. The motor details are 415 V / 50 Cycles / 3 Phase RPM 1500 / . First-class Chinese motor as standard. Siemens and ABB motor are optionals.
Speed inverter
An AC frequency inverter installed in a panel controls the RPM of the disperser shaft from 0-1500. The inverter is provided with settings for monitoring torque, amperage, voltage, power factor etc and is PC compatible.First-class Chinese speed inverter as standard. Siemens, ABB and Yaskawa speed inverter are optionals.
Electric Control Panel (Non-Ex proof)
A control panel is provided with the following functions. Main motors on off, ammeters, voltmeter, emergency stop, inverter trip, indicating lamps, speed control switch, RPM indicator. All internal wiring is per international codes of practice.
Electric Control Panel (Ex proof)
A remote control panel is provided with the following ex proof controls. Main motors on off, ammeters, voltmeter, emergency stop, inverter trip, indicating lamps, speed control switch, RPM indicator. All internal wiring is per international codes of practice. The inverter is installed in a separate panel and is to be installed in a safe Non-Ex proof zone.
Vessel (Optional)
The vessel is fabricated from SS plates and is provided with 3 nos castor wheels, SS bottom discharge ball valve and towing handles. All SS parts are duly polished inside and outside.
Main Technical Data:
Model | Power (kw) | Speed (rpm) | Disc dia (mm) | Lifting height (mm) | Capacity (L) | Weight (Kg) | |
ESFSA2.2 | 2.2 | 0-1450 | 150 | 600 | 100 | 160 |
|
ESFSA4.0 | 4.0 | 0-1450 | 200 | 700 | 200 | 210 |
|
ESFSA5.5 | 5.5 | 0-1450 | 250 | 800 | 400 | 240 |
|
ESFSA7.5 | 7.5 | 0-1450 | 300 | 900 | 500 | 280 |
|
