Industrial Inline high shear mixer for liquids chemicals
ESSW3 high shear Inline mixer doesn't simply mix. It emulsifies, homogenises, solubilises, suspends, disperses and disintegrates solids. Each mixer, with its precision engineered THREE stages rotor/stator workheads, far outperforms conventional mixers,improving quality, product consistency and process efficiency.
Features:
Suitable for industrial continuous production
Wide viscosity range than in batch high shear mixer
No batch difference
High efficiency, low noise
Main Technical Data
Capacity
Self-pumping throughputs of 20 to 20,000 litres/hr No Bypassing
Product cannot bypass the precision rotor/stator workhead.
Interchangeable Workheads
Three stagse rotor/stator configurations workheads as standard. For the rotor/stators configurations, 2,4 and 6 layers structures makes the best shearing result.
Materials of Construction
Product contact in SS304 or 316L stainless steel. Motor Specification
Standard and explosion proof motors (Siemens ,ABB etc) are available as standard.
Inlet and Outlet Connections
All sanitary screw or flange fittings available on request (e.g. ISS, D/N, RJT, SMS, Tri-clamp, etc.).
Sealing
Single or double mechanical shaft seals available as standard.
Cooling
Cooling jacket structure as standard
Technical Data:
Type |
Power KW |
Rotate Speed rpm |
Flow Rate m3/h |
Inlet |
Outlet |
ESSW3-40 |
4.0 |
3000 |
3 |
DN40 |
DN32 |
ESSW3-55 |
5.5 |
3000 |
5 |
DN40 |
DN32 |
ESSW3-75 |
7.5 |
3000 |
8 |
DN50 |
DN40 |
ESSW3-110 |
11 |
3000 |
12 |
DN65 |
DN50 |
ESSW3-150 |
15 |
3000 |
18 |
DN65 |
DN50 |
ESSW3-220 |
22 |
3000 |
22 |
DN65 |
DN50 |
ESSW3-370 |
37 |
1500 |
30 |
DN100 |
DN80 |
ESSW3-550 |
55 |
1500 |
40 |
DN125 |
DN100 |
ESSW3-750 |
75 |
1500 |
55 |
DN125 |
DN100 |
ESSW3-900 |
90 |
1500 |
65 |
DN125 |
DN100 |
ESSW3-1100 |
110 |
1500 |
80 |
DN150 |
DN125 |
ESSW3-1320 |
132 |
1500 |
130 |
DN150 |
DN125 |
