Specifications
1.Capacity:3000-12000bph2.Filling precision: 5mm
3.Bottle height: 150-320mm
4.Total power: 5.03kw
water filling machine
This sysries of monoblock filling machine are applied to the product of pure water, mineral water and non-carbonated dirnk, it integrates bottle washing, filling and capping into one body of the machine. It is very convenient to change bottle size by means of advanced bottle conveying technology--bottle neck clamping and bottle suspending technology.
Technical paremeter:
1. Filling capacity: 3000-12000 bottles per hour (base on 500ml bottle)
2. Filling precision: <5mm(liquid level)
3. Polyester bottle specification: bottle diameter: 50-100mm
4. Bottle height: 150-320mm
5. Suitable cap type: plastic screw cap
| Model: |
CGF16/12/6 | CGF16/16/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 |
| Production(500/m/bottle/h): | 3000 | 5000 | 8000 | 10000 | 12000-14000 |
| washing filling and capping heads | 16 12 6 | 16 16 6 | 18 18 6 | 24 24 8 | |
| Bottle size | Circular or square bottleBottle diameter(mm): Φ50-φ90 Bottle height(mm): 150-310 | ||||
| Compressed air pressure(MPa): | 0.3-0.7 | ||||
| Washing medium: | Aseptic water Washing | ||||
| waters pressure(MPa): | 0.25 | ||||
| Total output (KW): | 3.13 | 3.84 | 3.84 | 4.1 | 5.6 |
| Oerall dimensions(mm): | 2500x1500x2500 | 2500x1800x2500 | 3200x2200x2800 | 3400x2600x2800 | 3600x2800x3000 |
| Weight (kg): | 2500 | 3000 | 3500 | 4500 | 5000 |
