Help CenterWater Filling Machine
US$ 10,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Filling MachineUS$ 10,000 - 100,000MOQ: 1 Set -
Bottle Unscrambler 20000BPHUS$ 10,000 - 100,000MOQ: 1 Set
-
5L Water Filling MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
5L Automatic Water Filling MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
CGF Pure Water/Mineral Water Filling MachineUS$ 10,000 - 100,000MOQ: 1 Set
Condition
New
Application
Food, Beverage
Packaging Type
Case
Packaging Material
Wood
Automatic Grade
Automatic
Driven Type
Electric
Power
2.2kw
Place of Origin
Jiangsu, China
Brand Name
HY
Model Number
CGF16-12-6
Dimension(L*W*H)
2400x1650x2500
Weight
2500
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1. water filling machine2.capacity:1000-30000bph
ponents all from famous brand
4.Product:Mineral &purified water
filling machine
Product Description of filling machine
This series of mineral water filling machine/water filling line are applied to the production of pure water, mineral water, with optional capacity from 1,000 to 30,000BPH
It integrates bottle washing, filling and capping in one machine. The mineral water filling machine/water filling line is very convenient to change bottle size by means of advanced bottle conveying technology--bottleneck clamping & bottle suspending technology.
Product Feature of filling machine
Advanced programmable PLC is equipped to control the main machine. Main electronic components are all from famous international enterprises. All spare parts that may touch with water are made from high-quality stainless steel.
Product Specification / Models
Model: CGF16-12-6
Production capacity: 3000-4000b/h (basis on 500ml bottle)
Filling precision: ±5mm(liquid level)
Polyester bottle specification: bottle diameter:φ50-φ100mm
bottle height: 150-320mm
Suitable cap type: plastic screw cap
Total power: 2.2kw
Overall dimension: 2400×1650×2500mm
Total weight: 2500kg
Other type
| Model: |
CGF16/12/6 | CGF16/16/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 |
| Production(500/m/bottle/h): | 3000 | 5000 | 8000 | 10000 | 12000-14000 |
| washing filling and capping heads | 16 12 6 | 16 16 6 | 18 18 6 | 24 24 8 | |
| Bottle size | Circular or square bottleBottle diameter(mm): Φ50-φ90 Bottle height(mm): 150-310 | ||||
| Compressed air pressure(MPa): | 0.3-0.7 | ||||
| Washing medium: | Aseptic water Washing | ||||
| waters pressure(MPa): | 0.25 | ||||
| Total output (KW): | 3.13 | 3.84 | 3.84 | 4.1 | 5.6 |
| Oerall dimensions(mm): | 2500x1500x2500 | 2500x1800x2500 | 3200x2200x2800 | 3400x2600x2800 | 3600x2800x3000 |
| Weight (kg): | 2500 | 3000 | 3500 | 4500 | 5000 |
inner picture
Other products related to the whole line
adhesive labeling machine
shrink film wrapping machine
