Bottle Unscrambler 20000BPH

Specifications

1. suitable for unscrambling disordered polyester bottles.
2.Automatic bottle unscrambler
3.PLC Contral
4.CE

APPLICATION:
This machine is suitable for unscrambling disordered polyester bottles. The disordered bottles are carried into the storing-section of the ordering bottle machine, and with the help of the pushing force of the rotating disk, the bottles enter their position. With the function of the turning-bottle device and the air-flow, the bottles are ordered into bottle mouth-up-position and are carried into the next process with the air-transfering type conveying bottle system. The machine adopts PLC computer system, and its frequency-control system can adjust its production capacity.





Production capacity	500 ml - 20000 bph
Gas Source pressure	0.7 Mpa
Gas consuming volume	0.5 m3/min
Suitable bottle type	Ø50-Ø90
Power	2.20kw
Size	Ø2650x2290mm
Weight	5800kg
