Juice Filling Machine (3-in-1)

Juice Filling Machine (3-in-1) photo-1
US$ 10,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HY
Model Number:
RCGF
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name HY
Model Number RCGF

Specifications

adopt rise-drop filling valve design
person-machine inerface touch-screen,PLC,and inverter

Juice Filling Machine (3-in-1)

Usage:
The series equipment is used in hot filling and sealing of green tea, black tea, wulong tea and fruit juice. The machine integrates washing, filling, capping together. The design is scientific and reasonable. Its appearance is beautiful. Its operation and maintenance is convenient. The automation is high. It is good equipment for choosing hot drink filling machine

Main Technical Specifications

Model RCGF16-12-6 RCGF16-16-6 RCGF18-18-6 RCGF24-24-8 RCGF32-32-10
Production capacity (500ml)(b/h) 3000-4000 4000-5000 5000-6000 6000-8000 8000-10000
filling precision 1%(Liquid Level)
polyester bottle standard(mm) (Bottle Diameter):φ50-φ100;(Height):150-310
suitable cap shape Plastic Screw Cap
water pressure of washing bottle(MPa) 0.2-0.25
wash bottle consumption water (kg/h) 800 1200 1500 1800 2400
spraying position 5 5 6 8 12
dripping bottle position 3 3 3.5 4 7
gas source pressure(MPa) 0.6
gas consumption(m³/min) 0.1 0.1 0.4 0.4 0.5
power(kw) 2.2 2.2 3.75 4 5.6
weight(kg) 2500 3000 3500 4500 6000
dimension(LxWxH)(mm) 2350x1610x2250 2350x1750x2250 2480x1960x2250 3010x2180x2400 4000x2200x2500
