Specifications
1.Mainly for asphalt mix plant2. For 25-320t/h asphalt plant
3. Compact flame shape
4. energy saving
Coal burner Introduction:
RM First Choise Pulverized Coal Burner with a specially designed multi-stage air-driven structure to speak out of turn, can produce in a short time so that high-temperature pulverized coal swirl with burning completely, heat utilization high, smoke dust, efficient energy saving, improvement of working conditions, reducing labor intensity, etc.,RM pulverized coal burners are ideal for energy saving and environmental protection products.
General Parameters:
| Model | RM500 | RM1000 | RM1500 | RM2000 | RM3000 | RM4000 |
| Power | 31.25 kW | 41.25 kW | 66.25 kW | 78.75 kW | 138.45 kW | 202.95 kW |
| Rated coal consumption | 450 kg/h | 1000 kg/h | 1500 kg/h | 2000 kg/h | 2860 kg/h | 3660 kg/h |
| Mixture temperature control | 130-180°C | 130-180°C | 130-180°C | 130-180°C | 130-180°C | 130-180°C |
| Main machine | LTZ40 | LTZ80 | LTZ120 | LTZ160 | LTZ240 | LTZ320 |
| Coal pulverizer | FMJ40 | FMJ80 | FMJ120 | FMJ120 + FMJ40 | 2*FMJ120 | 3*FMJ120 |
| Oil burning igniter | RYDH | RYDH | RYDH | RYDH | RYDH | RYDH |
| Distribution cabinet | PD40 | PD80 | PD120 | PD160 | PD240 | PD320 |
| Combustion completeness | ≥95% | ≥95% | ≥95% | ≥95% | ≥95% | ≥95% |
| Matching asphalt plant output | 25-40 t/h | 70-85 t/h | 100-125 t/h | 140-170 t/h | 200-250 t/h | 280-320 t/h |
Requirements of fuel:
1. Use 0 # diesel for oil burning igniter;
2. Requirements for coal used for burning:
(1) Mark of coal: bituminous coal;
(2) Gross calorific value:≥5000kcal/kg (≥ 20000kJ/kg);
Net calorific value:≥4200kcal/kg;
(3) Volatile matter:≥25%;
(4) Ash Content: ≤10%;
(5) Total moisture: ≤35%;
(6) Inherent moisture:≤14%;
(7) Total sulphur:≤1%;
(8) Particle size:≤20mm.
Note: These indexes are the lowest requirements for the coal,
the better coal will be better at practice.
3. Environment friendly: combustion completeness ≥95%,
air black: Ringelmann 0-I grade, no harm to environment.
