M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base

M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-1
M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-2
M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-3
M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-4
M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-5
M-S5300 500m Communication Handheld 1d Laser Supermarket Cheap Wireless Barcode Scanner With the Base photo-6
US$ 39 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
CIS
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Barcode Scanner
Scan Element Type CIS
Colour Depth 32 Bit
Interface Type USB
Max Paper Size 30CM
Optical Resolution 4mil
Scan Speed 260 scans/sec
Brand Name MACWON
Model Number M-S5300
Place of Origin Shanghai, China
Product Description

500m communication handheld 1d laser supermarket wireless barcode scanner with pedestal

Features

1. The overall design of the product is delicate and exquisite. The head of the scanner, the handle and the base are protected by rubber, and the scientific inside struck design enhanced the crashproof function, which is unmatched by the common wireless barcode scanner in the market.

2. There is a new leap in the code reading function. With the new technologies of the decoding chip, the scanner can be read and transfer more quickly.

3. The easy setting procedure can make sure the client learn to use it quickly ,which avoid the complex setting when you use it..

4. The big capacity battery is 1.5 times of the common scanner , so our scanner can be use for a longer time.


5. The far transmission distance: ,i.e. 500m in the empty space(normally 50-200m in the room,which is according to the indoor structure.

6. Super larger memory: it can store 100,00-300,00 of barcode.

7. Powerful matching function: supporting 3 kind of work modes (one to one , one –to many and many-to-one). One receiver can receive messages from 255 pieces of scanner at the same time.

8. Uploading the date intelligently, it can upload the date breakpoints continuingly (the scanner will store the date in it’s own memory, when the date can not send to the computer successfully. And upload the date to the computer when it is convenient)

9. The stand-by mould technology can save the power, so it can use longer time.

1.Application

1.e-Ticketing
2.Electronic Coupon
3.Medical information management
4.Catalogue management
5.Client management
6.Order management
7.Document tracking
8.Public security management
9.Inventory management
10.Parcel transport management
11.Card manaegment
12.Fixed asset management
13.Equipment management
14. OA

2.Application Area

1. Retail industry
2. Medical industry
3. Airline
4. Logistics
5. Financial
6. Construction
7.Manufacturing
8. Gov and public

Function explanation:

1. Storage function: the scanner will automatically store the date in it’s own memory when the date can not upload to the computer successfully.(when the transfer distance is too far or there are other signal interruption). It guarantee the date will not be lose.

2. Low power alarm function: If the scanner enter the stand-by state when it is reading the barcode or when you just turn on it automatically and the indicators flickers continuingly at the meantime, it means the battery need to be charged.

3. Stand-by state: when it is not used , it will enter the stand-by state automatically.

4. Charging: Inserting the crystal plug into the interface of the scanner and inserting the usb plug into the computer’s usb interface. When the indicator is red , it means it is being charged.When the red indicator flames out, it means the battery is charged fully.

specifications
Source Type
Visible laser diode, wavelength 650nm
Trigger Mode
Manual
Scan Mode
Single scan
Scan speed
100 ± 2 times
Resolution
≥ 4mil
Print Contrast
30% minimum reflectance difference.
BER
1/5000000
Charging input voltage
DC 5VDC ± 0.25 V
Power: 100 mW (work)
400 mW (maximum instantaneous)
Current: 20 mA (work)
100 mA (maximum instantaneous)
Standby current
<20uA
The light intensity
3000-12000Lux
Depth of field
5mm-630mm
Scanning angle
± 60 ° ± 65 ° ± 42 ° (left and right, front and rear, turn)



Decoding capability
UPC / EAN / JAN, UPC / EAN with Supplementals, UCC / EAN 128,Code 39, MSI, Code11, Code 39 Full ASCII, Code 39 TriOptic, Code 128,Code 128Full ASCII, Codabar, Code93, Discrete2of5, IATA, RSSvariants,Codabar, Chinese2of5, Inteleaved2 / 5, Interleaved2of5, the postal code and other countries,Interpersonal GM - dimensional bar code

Scanner
L * W * H: 158mm * 68mm * 96mm
Weight
200g

Charging Interface Type
RJ-45 crystal head, length 1 m (with a USB charging cable, when the red light is charging ,When the red light is off the battery is full)

Shell Material
ABS + PC
Temperature
0 ℃ to 50 ℃ (work): -40 ℃ to 60 ℃ (storage)
EMC EMC
EN55022, EN55024
Electrical Safety
EN60950-1
Enclosure class
IP54
Seismic capacity
multiple drops from a height of 2 m to concrete still work
