Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Cummins Diesel Genset 100KW Diesel Generator
Cummins Diesel Genset 100KW Diesel Generator
US$ 5,000 - 8,000
MOQ: 1 Acre
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
ROBUST POWER
Model Number:
RSWL-100KW
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
ROBUST POWER
Model Number
RSWL-100KW
Output Type
AC Three Phase
Speed
1500/1800rpm
Frequency
50/60HZ
Rated Power
5KW~1000KW
Rated Voltage
230/400V
Rated Current
Voltage
| Rated frequency (Hz) | 50 |
| Rated output (Kw/Kva) | 100/125 |
| Rated voltage (V) | 400/230 |
| Rated current (A) | 180.4 |
| Rated speed (r/min) | 1500 |
| Circulated type Excitation mode | Three-phase, four wires Y type connection/Brushless self-excitation and constant voltage AVR |
| Power factor cosφ | 0.8lag |
| Insulation grade | H |
| Pole number | 4 |
| Engine model | R6105AZLD |
| Engine type | Four strokes, Water cooling, Inline, injecting combustion chamber,in-line |
| Displacement (L) | 6.49 |
| Compress ratio | 16:1 |
| Air Intake Mode | Turbo-charged,Intercooled |
| Bore * stroke (mm) | 6-105*130 |
| Rated power kW/(r/min) | 110/1500 |
| Fuel type | 0#(summer),10#(winter),35#(chill cold) diesel |
| Lube oil brand | SAE15W40(above CD grade) |
| Fuel consumption rate(g/kW.h) | ≤239 |
| Fuel tank capacity (L) | 268 |
| Continuous runnning time (H) | 8 |
| Overall dimension (L*W*H)(mm) | 3100*1100*1640 |
| Dry weight (Kg) | 1930 |
| Starting system | 24V electric starter |
| Noise level dB(A)/7m | 70 |
| Structure type | Super silent |
diesel generator
