GF3-20 diesel genset set is in perfect all-weather service property and the operation and performance are more stable. Using a special design and advanced noise reduction technology,we can reduce the noise to less than 75dB. More specifications as below:
Genset model | GF3-20 |
Rated power (Kw/Kva) | 20/25 |
Voltage (V) | 400/230 |
Current (A) | 36 |
Frequency (Hz) | 50 |
Power factor cosφ | 0.8(lagging) |
Excitation mode | Brushless self-excitation |
Phase/Connection | 3-phase 4-wire Y type connection |
Voltage regulation rated | ≤±1% |
Voltage Regulation | Automatic |
Insulation grade | H |
Engine model | Y4100G |
Engine type | Three-Cylinder(Y385G) Four-cylinder, 4-stroke, water-cooled, direct injection,in line,1500rpm |
Intaking method | Naturally Aspirated |
Bore × stroke (mm) | 100×105 |
Displacement (L) | 3.298 |
Compression ratio | 18:1 |
Rated power (Kw) | 25 |
Fuel consumption rate (g/kW.h) | <247.5 |
Lube consumption rate (g.kw.h) | <2.72 |
continuous running time (H) | ≥8 |
Governing method | Mechanical governor |
Starting system | DC 24V |
Dimensions(L×W×H)mm | 2000×900×1140 |
Net Weight (Kg) | 625 |
