China patented high efficiency Explosion-proof steel core belt bucket elevator
- 100 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- SZT-300 clinker bulk machine sand aggregate bulk head fixed car loader
- Cement depot bottom arc discharge valve B300 pneumatic flow control valve Electric flow control valve
- Air chute pneumatic two-way valve chute electric T-valve steering valve
- Cement bulk dust removal machine base bulk machine automotive bulk dust collection equipment
- XZ500 air transport chute cement plant air transport aircraft ore powder transport equipment
- SZ-I50 dry powder cement warehouse bottom bulk machine Fixed truck bulk head
Product Details
Place of Origin: | Hubei, China | Brand Name: | TianYi | Model Number: | TDG |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China patented high efficiency Explosion-proof steel core belt bucket elevator
High Efficiency vertical explosion-proof steel core belt bucket elevator
TDG series steel core belt bucket elevator, with the anti-tearing wire rope core belt as the traction parts.
Explosion-proof steel cord belt bucket elevator patent.
Patent No. : ZL 201420366104.X
Main Features
1) Adopting steel cord belt as drag parts.
2) The head section, tail section and middle section of this elevator made effective seal processing.
3) This elevator is centrifugal discharging, pick and get charging.
4) Driving device adopting vertical shaft reducer and fluid coupling.
5) The bottom section of this machine have level indicator and speed sensor, Monitor the running status of elevator.
Name: steel buckets
Brand: TIANYI
Original:CHINA
Head section & Tail section
Upper section(head section) is made of drive sprocket, top case, in half cover and drive plate. Drive sprocket running make the chain buckets move from bottom to top, then lift the material.
Lower section (Tail section) is made of take-up sprocket group, bottom case, heavy hammer tension device, inlet, skirt plate and inspection door. Take-up device with the aid of a heavy hammer and the self weight of take-up sprocket group. Make the chain’s tension constant. When the chain wear elongation, can automatic adjustment the wheel base.Inspection door is convenient for take apart the buckets and chains.Lower door is used for cleaning the material.
Pre-Sales Service
* Inquiry and consulting support.
* Technical drawings support.
* View our Factory.
After-Sales Service
* Support installations and training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
