TD series Bucket Elevator, full name is belt type bucket elevator, with the high-strength rubber belt for traction parts.

TD Series Bucket Elevator is suitable for those powder, granular, small block of no grinding bulk material, such as grain, coal, gravel, sand, coke foam, cement, gravel mine, silicate etc. The temperature of the conveying material should not be commonly higher than 80 ℃; When choosing heat- resistant belt, it should not exceed 200 ℃.

Main Features

1) Simple structure ,easy in installation and maintenance.

2) Adopting best rubber belt and plastic buckets.

3) Huge capacity can reach to 800t/h.

4) Food grade standard.

Machine Parts

Name:  belt bucket elevator

Brand: TIANYI

Original: CHINA

Name:   steel buckets
Brand: TIANYI
Original:CHINA

Head section & Tail section

Upper section(head section) is made of drive sprocket, top case, in half cover and drive plate. Drive sprocket running make the chain buckets move from bottom to top, then lift the material.
Lower section (Tail section) is made of take-up sprocket group, bottom case, heavy hammer tension device, inlet, skirt plate and inspection door. Take-up device with the aid of a heavy hammer and the self weight of take-up sprocket group. Make the chain’s tension constant. When the chain wear elongation, can automatic adjustment the wheel base.Inspection door is convenient for take apart the buckets and chains.Lower door is used for cleaning the material.
