2016 Best Sells JQX-62F Power Relay With 24v dc
US$ 4.5 - 5.3
/ Piece
1 Piece(Min. Order)
- Ningbo or Shanghai
- T/T Money Gram
You May Like
-
The Best Seller,electrical Relay With 12v 220v G2R
-
Momentary Voltage Drops for G7L Relay,A High-capacity With Air Condition Refrigerator Power Relay
-
Power-switching Compact General-purpose Relays LY2 Relay
-
2016 Best Sells Latching Relay JQX-115F With 16A SPST.
-
ST3P Time Relay,1-60s Delay Time
-
Best Quanlity 5 Pin JD1912 Auto Relay 12v 30a
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Nobel | |
| Model Number | JQX-62F 2Z | Theory | Voltage Relay | |
| Usage | General Purpose | Size | Miniature | |
| Protect Feature | Epoxy | Contact Load | High Power |
Product Description
CHRE 2016 best sells JQX-62F power relay with 24v dc
Product Description
What is the Features of the Electromagnetic Relays?
Appearance: 100A Contact Change-over capacity
With opening and dust-proof type
Dielectric strength(Between coil and contact): 2,500VAC
Ambient temperature: -40℃ ~+70℃
Operate/release time: 25ms/25ms
(min) Mechanical life: 1*10^7
(min) Electrical life: 5*10^4
Technical Specificat
| Dimensions(mm) | 68.2*62*84 | |
| Contact form | 2Z | |
| Contact capacity | 120A,250VAC; 120A,30VAC | |
| Coil voltage | DC | 6-220V |
| AC | 6-380V | |
| Coil power | DC≤2w,AC≤3.2VA | |
| Pick up | DC:≤75%,AC≤80% | |
| Drop-out | DC≥10%,AC≥30% | |
| Contact resistance | ≤50mΩ | |
| Insulation resistance | ≥100mΩ | |
| Service life | Electrical | 10^5 times |
| Mechanical | 10^5 times | |
| Dielectric strength | Between open contacts | 1500v rms |
| Between coil & contacts | 2500v rms | |
| Operation temperature | -40°c-+55°c | |
| Weight | About 340g | |
