27W constant current 300ma led driver ip66 300ma power supply waterproof
• 2 years warranty
(We promise to replace new ones to you if there is any defective happen during the warranty period)
Description:
- input: 100~265vAC, 47~63Hz
-
output current: 300ma 75-90v 27w
- High efficiency,save energy ,protected environment
- High stability and low ripple, increase light efficiency and decrease light attenuation
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage
- Passed high ,low temperature and waterproof testing.
- Integrity protection,over loading, over voltage ,over current
- 8Hrs and 100% full load burn-in test.
Specification
• Case material--Alumium housing
• Cooling by free air convection
• 100% full load burn-in test
• Waterproof rate: IP67
• High reliability designing solution
• Suitable for LED lighting and moving sign applications
• CE,UL, ROHS approval
Environment:
- Working Temperature : -30 ~ +60°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety:
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Product parameters:
Model |
Input voltage (vAC) |
Working Frequency (Hz) |
Output voltage (vDC) |
Output Current |
power (Watt) |
Working Temp. |
Protection grade |
SMT-090-0300CW |
100-265vAC |
47~63Hz |
75-90V |
300mA |
27W |
-40~50°C |
IP67 |
SMT-080-0350CW |
100-265vAC |
47~63Hz |
60~80V |
350mA |
28W |
-40~50°C |
IP67 |
SMT-040-0700CW |
100-265vAC |
47~63Hz |
20~40V |
700mA |
28W |
-40~50°C |
IP67 |
SMT-036-0840CW |
100-265vAC |
47~63Hz |
20~36V |
840mA |
30W |
-40~50°C |
IP67 |
SMT-028-1050CW |
100-265vAC |
47~63Hz |
15~28V |
1050mA |
29W |
-40~50°C |
IP67 |
Application:
Our products are widely used in various industries, such as
- Outdoor LED illuminating lights,
- LED Neon,
- LED City Decoration,
- LED Lighting Advertising,
- LED Display,
- Safety Protection Apparatus,
- Telecommunications,
- Networks,
- Vehicle Lights,
- Controller Panels, etc.
Packing
Production Certificate
Equipments
Factory
