10.4'' cctv touch screen color monitor with VGA ,USB
Negotiable
/ Piece
100 Pieces(Min.Order)
- 8000 Piece / Pieces per Month
- shenzhen/hongkong
- Credit Card
You May Like
- 12.1" SVGA Open Frame Touch Screen Industrial LCD Display (LCD Module)
- 7" Open Type Module (OTM) Touch Screen Industrial LCD Display
- 7" Open Type Module (OTM) Touch Screen Embedded LCD Monitor
- 17" Wide Open Frame Touch Screen LCD Monitor (LCD Module)
- 19" Wide Open Frame Touch Screen LCD Monitor (LCD Module)
- 12.1" XGA Open Frame Touch Screen Embedded LCD Monitor (LCD Module)
Product Details
Products Status: | Stock | Screen Size: | Other, 10.4'' | Type: | Resistive |
Interface Type: | D-Sub, USB | Resolution: | 800 x 600 | Brand Name: | AZUQI |
Model Number: | AKA-104M | Place of Origin: | Guangdong, China |
Product Description
10.4'' cctv touch screen color monitor with VGA ,USB
Specification | ||
Model No. | AKA-104MA | |
Display | Screen size | 10.4'' (4:3) |
Panel type | TFT Color LCD | |
Pixel Pitch | 0.33mm | |
Brightness | 380 cd/square meter | |
Contrast ratio | 300:1 typical | |
Viewing Angle(U/D/L/R) | 65/65/45/60 | |
Display color | 262K | |
Response Time | 8ms | |
Power Consumption | Approx. 15 Watts | |
Video system | NTSC / PAL | |
Interface | Solution No. | VGA |
PC-RGB Input | VGA (15Pin D-Sub)x 1 | |
Audio Input | Stereo 3.5mm input x1 | |
USB (for touch use) | 5 Wires resistive touch | |
DC 12V Input | 1 | |
Features | Built in Comb Filters | No |
Built in De-interlace | No | |
Source | VGA | |
Multi-Language | English, Chinse,French ,German, | |
Italian , Portuguese , Spanish | ||
Audio | Built in Speakers(Option) | 2 |
Cabinet | Color | Black |
Material | ABS Plastic | |
Wall Mount | VESA | |
Base Stand | Desktop Stand | |
Circumstance | Operating Temperature | 0°C ~ 50°C / 32°F~122°F |
Storage Temperature | 20°C~60°C / 4°F~140°F | |
Packings | Unit N.W./G.W. | Approx. 1.2KG/2KG |
Gift Box Dimension | 330x133x355 mm (LxWxH) | |
Regulations | RoHs , FCC , CE , C-tick , and so on. | |
Specification are subject to change without notice |
Interface for your reference:
Picture for your reference:
