Double Action Deep Drawing Hydraulic Press
1.Suitable for:
Double Action Deep Drawing Hydraulic Press is suitable for pressing Aluminum products and stainless steel products,which is particularly used for drawing aluminum sheet,pressing and forming aluminum products,drawing stainless steel sheet,as well as pressing and forming stainless steel products.
2.Main Feature:
A.The deep drawing force speed is adjustable
B.Speed control of the second section of moving beam;No-load rapid &slow copy deep drawing
C.Designed and manufactured specially for the industries of aluminum products and stainless steel products,which is particularly used for drawing aluminum sheet,pressing and forming aluminum products,drawing stainless steel sheet,as well as pressing and forming stainless steel products.
D.The hydraulic components,electrical components and sealing parts of this series of machine are all imported famous-brand products.
3.Main technical specification:
DESCRIPTION | UNIT | Y28-800 |
Nominal Capacity | KN | 5000 |
Main Cylinder Pressure | Mpa | 26 |
Return Capacity | KN | 290 |
Blankholder Cylinder Capacity | KN | 3000 |
Blankholder Cylinder Max. Pressure | Mpa | 24 |
Upper Ejector Capacity | KN | 60 |
Ram Stroke | MM | 700 |
Blankholder Stroke | MM | 350 |
Ejection Stroke | MM | 320 |
Downing Speed | MM/S | 120 |
Pressing Speed | MM/S | 10~17 |
Return Speed | MM/S | ≥190 |
Motor Power | KW | 55+1.5 |
Working table size | MM | 1300(L) x 1500(W) |
Overall Size | MM | 2300(L) x 1900(W) x 5140(H) |
1.The special specification can be custom made separately
2.Engineer is available to service oversea
