Specifications
Automatic A4 Paper Cutting Machine1.Automatic type ,4-5T/8hour
2.Roll paper cutting
3.PLC,Servo control
4.In stock
Detail of A4 Paper Cutting Machine
High Speed A4 Paper Cutting Machine Use and characteristics:
This machine is mainly used in the production of A3, A4 copy paper cutting.Servo motor to control the cutting length, with high precision, mechanical stability, less waste and so on
This machine is suitable for all kinds of paper, paper plastic compound class, color printing compound packing material type and other large roll cut-off cut. 1. This machine adopts PLC touch screen control, servo motor, control, fixed-length cut. 2. Transmission using pneumatic, photoelectric sensors, centralized control, the machine set of light, electricity, gas one, simple, shear and high precision, mechanical stability, low noise. 3. Motor speed regulation, automatic counting, alarm stop, and magnetic tension control. Can longitudinal sections of cutting, waste side with fan automatically excluded.
a3 a4 Paper Cutting Machine Price Products Details:
Model |
DK-1100 |
DK-1300 |
Effective width |
1100mm |
1300mm |
Maximum diameter of raw materials |
Φ1400mm |
Φ1400mm |
Minimum width of vertical cut |
50mm |
50mm |
Cutting Length |
20-400mm |
20-400mm |
Cutting speed |
10-140m/min |
10-140m/min |
Cutting precision |
±0.2mm |
±0.2mm |
Total power |
19kw |
20kw |
Weight |
7000kg |
7500kg |
Dimensions(L×W×H) |
17500x1950x2000mm |
17500x2250x2000mm |
Skype: ritayuan99
Welcome To Contact Me
Finished A3 A4 Paper Usage:
Automatic A4 paper Stacker:
The A4 Paper Cutting Machine Feeding Unit: Roll Paper As Raw Material , with air cylinder
The Paper Cutting Machine Magnetic powder: Tension Control
A4 Paper Cutting Machine Electric Error Controller :
The Paper Cutting Machine Circular Knife and Flat Knife For Cross Cutting And Length Cutting: with Srvo motor control
A4 A3 Roll Paper Cutting Machine --Computer Control Plate: With PLC
Roll A4 Paper Cutting Machine Traction Unit :
A4 A3 Paper Cutting Machine Complete Line :
Four Paper Roll Material Feeding : 4-5T/8hours
Two Paper Roll Feeding Model: 2-3T/8 hours
