High Speed DKHHJX-1100-1600 Servo Control Automatic Cross Paper Cutter Machine
- 10 Set / Sets per Month
- Ningbo Or Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Leizhan Disc sludge thickener for paper pulp making production line
- 2013HOT SELL Stainless steel structure Disc thickener for paper pulp making production line
- Disc pulp filter machine of fluting and kraft paper production line
- Leizhan waste paper recycle equipment ZNP series disc thickener/paper processing equipment/paper pulp machinery
- disc thickener/paper pulp industrial use
- disc thickener used for washing and thickening/paper making industry
Product Details
Condition: | New | Type: | Paper Cutting Machine | Computerized: | Yes |
Place of Origin: | Zhejiang, China | Brand Name: | Duke | Model Number: | DKHHJX-1100-1600 |
Voltage: | 380v | Power(W): | 10KW | Dimension(L*W*H): | 6650x1600x1800 |
Weight: | 5000kg | Certification: | AAA ISO | Warranty: | One Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Cross Paper Cutter Machine1.10-100 times/min
2.feed diameter:800-1600mm
3.paper trimming and collecting
Detail of High Speed DKHHJX-1100-1600 Servo Control Automatic Cross Paper Cutter Machine
Cross Paper Cutter Machine Use and characteristics:
This Cross Paper Cutting Machine is suitable for color printing complex film or 100g-500g simple materials such as paper rolls cut,longitudinal section. Servo motor control fixed-length truncation, photoelectric tracking correction, simple material was added to our pressure to upgrade, automatic lift table features automated management certificates of compliance. The electric machine assembly
machine liquid gas integration, high precision, easy operation.
Paper Cross Cutter Machine Main technical parameters:
Model | 1100 | 1300 | 1600 |
Maximum cutting width | 1100mm | 1300mm | 1600mm |
Maximum diameter of raw materials | 1400mm | 1400mm | 1400mm |
Truncation length | 20-1999mm | 20-1999mm | 20-1999mm |
Precision of fixed | ±0.2mm | ||
Productivity | 100m/min | ||
For power | 380v/50Hz | ||
Total power | 10kw | 11.5kw | 13.5kw |
Weight | 2200-5800kg | 2200-5800kg | 2200-5800kg |
Dimensions (mm) | 6650×1600×1800 | 6650×2400×1800 | 6650×2900×1800 |
Finished Paper samples:
Unwind part: equipped with magnetic brake and gas chamber for paper reel holder
Cross Paper Cutter Machine: crosscut blade and conveyor
Magnetic powder: Tension Control
Welcome Contact me or Visit us anytime
Our Service
we will send technician to install and training your work after the machine arrived your factory,another questions about machine can talk with me online,we will solved it within 2days.
FAQ:
1.Q:Are you a factory or trade company?
R:We are a factory for Paper Cutting Machine Manufacture
2.Q:Where is your company located?How can I visit there?
R:Our company is located in Ruian City,Wenzhou area,Zhejiang province,China.
About 1 hour by plane from Shanghai to Wenzhou,then 1 hour taxi to our place(5 hours by fast
train to Ruian station)
3.Q:what is the raw material does the machine ?
R:the material is Roll Paper
4.Q:who can answer my urgent questions about the machine?
R:leave a message when I am not online,will reply you within 24hours.
5.Q:how does your factory do regarding quality control?
R:our company policy is “quality first,customer first”.we have a QC manager whom check
the machine making from beginning to the end.
