Specifications
1.8 Folded Garbage Bag Making Machine2.30 M/minute
3.sevor motor control
4.Have stockage
5.8 fold star bags
The rolled bag machine specializes in producing plastic rolling flat and vest bags,
controlled by stepping motor or servo motor.
The handle part of vest bags can be punched automatically by machines.
The device is based on the export of film packaging bag business requirements,
develop and produce their own set of light, electricity, gas, and instrument.
Mainly applied to LDPE, HEPE and other hot melt film bag making machine.
With photoelectric control automatic feeding, photoelectric control pneumatic components sealing,
photoelectric tracking system, automatic counting, to the number of automatic conversion,
a pedal pneumatic, regular collection, is not stop production even roll" S" type and
twenty percent off continuous winding vest bag the ideal equipment.
8 Folded Garbage Bag Making Machine Main Technical Variables:
Model | YT-350 |
Width of Bag-making | 20-350mm |
Bag length | 20-1800mm |
Bag Making Speed | A minute 30 meters to 40 m |
Bag Making Thickness | 0.024-0.380mm |
Bag Making Varieties | Color printing bag, white bag, garbage bags. |
Type of Bag Making | Even the roll eighty percent vest bag, even roll S type eighty percent bag |
Total Power | 4.8Kw |
Overall Dimension | 4500×1300×1200mm(L*W*H) |
Weight | 800kg |
8 Folded Garbage Bag Making Machine Configuration list:
NO. | Goods name | quantity | Place of origin |
1 | Main Motor | 1piece | Zhejiang province Ruian City LIDAR Motor Company Limited |
2 | Rear feeding motor | 1piece | Zhejiang province Ruian City LIDAR Motor Company Limited |
3 | Before receiving motor | 1piece | Zhejiang province Ruian City LIDAR Motor Company Limited |
4 | Before feeding speed control board | 1piece | Zhejiang province ruian city |
5 | Rear feeding speed control board | 1piece | Zhejiang province ruian city |
6 | Computer controller | 1set | Ruian brilliant electronic control machine Co., LTD |
7 | Step feeding motor | 1piece | Ruian brilliant electronic control machine Co., LTD |
8 | Drive controller | 1piece | Ruian brilliant electronic control machine Co., LTD |
9 | Frequency converter | 1piece | Zhejiang China blue group |
10 | Photoelectric eye color tracker | 1piece | Zhejiang province Longyou City |
11 | Discharge controller | 1piece | Zhejiang province Longyou City |
12 | Point break tooth cutter | 1set | The factory manufacturing |
13 | Flat hot knife | 2sets | The factory manufacturing |
14 | Temperature control table | 2piece | Zhejiang province Wenzhou City |
15 | Rolling equipment | 1set | The factory manufacturing |
The optional choose configuration:
Servo stepper and servo driver (Japan Yasukawa)
Inverter (Japan Yasukawa)
Electric light (peaceful)
Temperature control table (Omron)
Photoelectric switch (Fu)
The host machine (Siemens)
Spare parts list :
No. | Item | quantity |
1 | Spring | 50 pieces |
2 | Teflon cloth | 1 piece |
3 | Oilcan | 1 set |
4 | Adjustable spanner | 1 piece |
5 | Allen wrench | 1 set |
6 | Carbon brush | 4 pieces |
7 | Relay | 2 pieces |
8 | Thermocouple | 1 piece |
9 | Heater band | 6 pieces |
Rolling Garbage Bag Samples:
Garbage Bag Making Machine Pic :
Bag Making Machine Computer Control:
T-shirt Garbage Bag Samples:
The Bag Making Machine Punchine Unit
The bag making machine workshop:
The film blowing machine workshop:
