Technical Parameters for corrugated sheet forming machine
1.Suitable material
Type:galvanized steel.Thinkness:0.4-0.7mm.Yide Strength:230-300Mpa.Width:1000mm.Wt of the Coil:5t.OD: ∅ 1350MM.ID:∅ 508mm/∅610mm
2Matrial of roolers:45# steel with chrome plate
3.Forming speed:About 20m/min
4.Power source:AC380V,50HZ,3 phase.Dimension:see the layout.Total power:About 9kw
Working process for corrugated roof roll forming machine
Decoiler ---Guiding system---Roll forming---Post cutting---outing put finished products to supporter
Components Parts of the Currugated sheet Roll Forming Machine
| Decoiler system | 1 set |
| Roll Forming system | 1 set |
| Feeding Guide Device | 1 set |
| Post-cutting system | 1 set |
| Hydraulic station | 1 set |
| PLC controlsystem | 1 set |
| Product supporter | 1 set |
Container packaging of the line suitable for overseas shipping
We can arrange our technician to go to abroad,but all the relevant cost should in buyers.
We provide technical support for whole life of our machine.
BOTOU JINBAILI ROLL FORMING MACHINE CO.,LTD Iis specially in roll forming machine 15 yeaars.Main products are glazed tile machine,c z u purlin machine,floor deck forming machine.highwar guardrail machine.
CUSTOMER VISIT
Q:How is this machine's service life?
A:In the normal maintenance,the service life at least 8 years.
Q:How to maintenance?
A:If using frequently,best coating lubricant on the chain and two ends of the shaft every month,
replace the hydraulic oil every 1-2 years.
Q:What can you do if the machine broken?
A:Our machine's warranty period is 1 year,if the broken parts can't repair,
we can free send the new parts replace the broken parts to you except the solenoid valve,the solenoid valve you must pay the express cost yourself.
if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.
Q:Can you be responsible for transport?
A:Yes,please tell me the destination port or address.
we have rich experience in transport.
Q:Mr.Alan,can you make the machine according to my design or proto type?
A: Yes. We have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us.
Q:How many workers operate this machine to manufacture?
A:Only 4 workers.
Q:Can you supply the raw materials?
A:Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
