Condition New
Type Rubber Mixer
Place of Origin Shandong, China
Brand Name PLASTSEA
Voltage 380V/50HZ
Dimension(L*W*H) 3100*1300*245 etc
Weight 20~80 ton
Certification ISO9001 CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



 Professional manufacturer of rubber internal mixer

——PLASTSEA MACHINERY CO., LTD



Product Description

Application of Our Banbury Mixer

 It's suitable for plastic and rubber mixing. The mixing chamber adopts special left-middle-right structure which makes maintenance easy.



Advantages of Banbury mixer:

1. Intermeshing or tangential rotor;

2. Rotors, mixing chamber, harmmer and parts which contacts with the material are overlayed with 5mm wear-resistant alloy       (up to 50HRC);

3. Pneumatic / hydraulic type top mounted hammer;

4. Inverted AC motor / variable speed DC motor;

5. Copper-ring and hydraulic sealing;

6. 2-wing, 4-wing, 6-wing are available;

7. Excellent dispersing effect;

8. Best mixing rotor and chamber to guarantee 100% mixing effect;

9. Low noise, safe mixing;

10. Maintenance friendly and long-life service



1. Banbury mixer for rubber:

Items

LX-75L

LX-100L

LX-120L

LX-160L

LX-190L

LX-255L

LX-270L

LX-410L

Total chamber volume(L)

75

100

120

160

190

255

270

410

Useful chamber volume (L)

50

80

100

120

140

115

188

319

The main rotor speed(rpm)

40

40

40

40

40

4-40

6-60

4~40

6~60

The rotor speed ratio

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

Max capacity (T/H)

1.25

1.6

1.95

2.64

2.85

4.6

4.6

7.4

Motor power (KW)

160

220

310

355

870

1500

1250

2X1250

Weight(T)

20

24

26

26

30

55

55

76



2. Banbury mixer for plastic:

ProjectModel

S-75L

S-100L

S-120L

S-160L

S-255L

S-270L

S-410L

Working capacity of mixing chamber(L)

75

100

120

160

255

270

410

Rotating speed of rear rotor(r/min)

40

40

40

40

40

40

40

Main motor power(kw)

160

220

300

400

1100

1250

2500

Pressed of compressed air(MPa)

0.6

0.6

0.6

0.6

0.58

0.58

0.62

Weight(t)

20

22

28

32

55

60

76





Intermesh Rotors  (high mixing effects)

Model

LH-100Y

LH-145Y

LH-200Y

LH-250Y

LH-330Y

Chamber Volume (L)

100

145

200

250

330

Filling Coefficient

0.65

Rotor Speed (r/min)

10-60

Rotor Speed Ratio

1:1.17

Max. Capacity (T/H)

1.36

2.2

3.05

4.2

5.0

Motor Power (Kw)

520

720

1100

1320

1700

Dimension (m)

6.6x2.8x4.4

7.5x3.1x5.5

8.1x3.5x5.4

8.2x3.8x5.5

10.0x4.7x6.6

Weight (T)

19

29

48

65

80























Banbury rubber kneader/ internal mixer

Banbury rubber kneader/ internal mixer

Specifications

Rubber banbury internal mixer
1.Drop-type discharge
2.Pneumatic and Hydraulic ram
3.Kinds of rotors

Rubber  banbury internal mixer



This mixer is used for final mixing and master batch mixing of tyre industry.



We can supply the mixer as below:



GK series (Technology W&P):

N type: GK-110N,GK-225N,GK-270N,GK-300N,GK-400N,GK-430N,GK-650N ,etc.

E type: GK-5E,GK-20E,GK-45E,GK-90E,GK-135E,GK-190E,GK-250E,GK-320E,GK-420E,GK-580E,etc.



F series (Technology Farrel)

F270L,F370L,F650L, etc.

XM-160,XM-20,XM-370,XM-650 ,etc.



The rubber mixers which we supply are the top level mixers in China industry, and also are used in many famous tyre factories around the world.

Banbury rubber kneader/ internal mixer



Banbury rubber kneader/ internal mixer







Company Information

 As a professional machinery  supplier,Plastsea Corp. was established by an experienced and professional team.It's located in Qingdao city which is the rubber&plastic industry center of China with the top level institute and university .

After several years developing,Plastsea has offered its excellent service and products to more than 30 countries in the world.

At present ,Plastsea focuses on Rubber and Tyre industries.Through joint-venture and cooperation methos,Plastsea has developed eight fabrication bases in China.The products cover internal mixer,twin-screw sheer,batch off cooling molds,tyre building drum,tyre bladder,tyre bladder mold,etc.

 Banbury rubber kneader/ internal mixer



 Welcome to visit our company and we can show you the machine in working condition:

 If our products win your interest, please send us inquires and we will provide detailed information to you. We can also make machines according to your request.
