High Quality Rubber Internal Mixer From Plastsea

High Quality Rubber Internal Mixer From Plastsea thumbnail-1
High Quality Rubber Internal Mixer From Plastsea thumbnail-2
High Quality Rubber Internal Mixer From Plastsea photo-1
High Quality Rubber Internal Mixer From Plastsea photo-2
US$ 10,000 - 350,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rubber Mixer
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Qingdao Plastsea International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rubber Mixer
Place of Origin Shandong, China
Brand Name PLASTSEA
Model Number GK-N GK-E
Voltage 380V/50HZ
Dimension(L*W*H) 3100*1300*245 etc
Weight 20~80 ton
Certification ISO9001 CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



 Professional manufacturer of rubber internal mixer

——PLASTSEA MACHINERY CO., LTD





  higher efficiency rubber kneader / banbury mixer / internal mixer with best rotors

Product Description

Application of Our Banbury Mixer

 It's suitable for plastic and rubber mixing. The mixing chamber adopts special left-middle-right structure which makes maintenance easy.



Advantages of Banbury mixer:

1. Intermeshing or tangential rotor;

2. Rotors, mixing chamber, harmmer and parts which contacts with the material are overlayed with 5mm wear-resistant alloy            (up to 50HRC);

3. Pneumatic / hydraulic type top mounted hammer;

4. Inverted AC motor / variable speed DC motor;

5. Copper-ring and hydraulic sealing;

6. 2-wing, 4-wing, 6-wing are available;

7. Excellent dispersing effect;

8. Best mixing rotor and chamber to guarantee 100% mixing effect;

9. Low noise, safe mixing;

10. Maintenance friendly and long-life service



1. Banbury mixer for rubber:

Items

LX-75L

LX-100L

LX-120L

LX-160L

LX-190L

LX-255L

LX-270L

LX-410L

Total chamber volume(L)

75

100

120

160

190

255

270

410

Useful chamber volume (L)

50

80

100

120

140

115

188

319

The main rotor speed(rpm)

40

40

40

40

40

4-40

6-60

4~40

6~60

The rotor speed ratio

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

1:1.17

Max capacity (T/H)

1.25

1.6

1.95

2.64

2.85

4.6

4.6

7.4

Motor power (KW)

160

220

310

355

870

1500

1250

2X1250

Weight(T)

20

24

26

26

30

55

55

76



2. Banbury mixer for plastic:

ProjectModel

S-75L

S-100L

S-120L

S-160L

S-255L

S-270L

S-410L

Working capacity of mixing chamber(L)

75

100

120

160

255

270

410

Rotating speed of rear rotor(r/min)

40

40

40

40

40

40

40

Main motor power(kw)

160

220

300

400

1100

1250

2500

Pressed of compressed air(MPa)

0.6

0.6

0.6

0.6

0.58

0.58

0.62

Weight(t)

20

22

28

32

55

60

76





Intermesh Rotors  (high mixing effects)

Model

LH-100Y

LH-145Y

LH-200Y

LH-250Y

LH-330Y

Chamber Volume (L)

100

145

200

250

330

Filling Coefficient

0.65

Rotor Speed (r/min)

10-60

Rotor Speed Ratio

1:1.17

Max. Capacity (T/H)

1.36

2.2

3.05

4.2

5.0

Motor Power (Kw)

520

720

1100

1320

1700

Dimension (m)

6.6x2.8x4.4

7.5x3.1x5.5

8.1x3.5x5.4

8.2x3.8x5.5

10.0x4.7x6.6

Weight (T)

19

29

48

65

80























High quality Rubber internal mixer from Plastsea

Specifications

1.The rolls of this machine is elliptical type rotor. The working surfaces of the rotor is made of welded wearable hard alloy. The working surface of the mixing chamber and the pressing ram device are experienced the treatment of hard chrome plating,which is corrosion-proof and has long service life.



2.The transmission device adopts NGW hard tooth flank planet reducer, which has compact structure, low noise and high efficiency.



3.The pressing ram device can add pressure to the materials through air cylinder or oil cylinder, to make the materials mix evently, upgrading the production efficiently and matching with the electrical control.The pressing ram device can fulfill automatic pressurization, decompression and floating.



4.The electric control system can be handled manually and automatically and the operation is reliable and the change is convenient. We adopt ordinary apparatus and PLC programming control. The client can choose according to his own requirements.



5.The machine adopts rear feeding and hydraulic tilting device for discharging. So the operation is steady and reliable. It is very convenient to clean the materials and change the colors.



6.Used in the plastic ting ,mixing and final refining of rubber and plastic material.



Rubber  banbury internal mixer



This mixer is used for final mixing and master batch mixing of tyre industry.



We can supply the mixer as below:



GK series (Technology W&P):

N type: GK-110N,GK-225N,GK-270N,GK-300N,GK-400N,GK-430N,GK-650N ,etc.

E type: GK-5E,GK-20E,GK-45E,GK-90E,GK-135E,GK-190E,GK-250E,GK-320E,GK-420E,GK-580E,etc.



F series (Technology Farrel)

F270L,F370L,F650L, etc.

XM-160,XM-20,XM-370,XM-650 ,etc.



The rubber mixers which we supply are the top level mixers in China industry, and also are used in many famous tyre factories around the world.



 High quality Rubber internal mixer from Plastsea



Company Information



As a professional machinery  supplier,Plastsea Corp. was established by an experienced and professional team.It's located in Qingdao city which is the rubber&plastic industry center of China with the top level institute and university .



After several years developing,with high quality, reasonable price, and excellent service, we have built up long and stable business relationship with customers covering more than 30 countries and regions over the world.



At present,Pleatsea focuses on Rubber and Tyre industries .Through joint-venture and cooperation method,Plastsea has developed eight fabrication bases in China.The products cover internal mixer,twin-screw sheeter,batch-off cooling machine,mixing mill,AGR/OTR tire building machine,cord fabric cutter,tire curing press,inner tube machines,tire molds,tire building drum,tire bladder,tire bladder mold,etc.

 High quality Rubber internal mixer from Plastsea



 Welcome to visit our company and we can show you the machine in working condition:

 If our products win your interest, please send us inquires and we will provide detailed information to you. We  can also make machines according to your request.
