Rubber Banbury Internal Mixers China Plant
- 280 Set / Sets per Month
- qingdao
- T/T
Product Details
| Condition: | New | Type: | Rubber Mixer | Place of Origin: | Shandong, China |
| Brand Name: | PLASTSEA | Voltage: | 220v 230v 380v 440v | Power(W): | 48kw 54kw |
| Weight: | 20t~76t | Certification: | ISO9001 CE | Warranty: | 12 months |
Product Description
Rubber Banbury Internal Mixers China Plant
——PLASTSEA MACHINERY CO., LTD
Rubber Banbury Internal Mixer/ Banbury Internal Mixer / Rubber Mixing Mill / Rubber Kneader
GK-E type (Most suitable for Master batch) Plastsea
Model Parameter | GK-45E | GK-90E | GK-E190 | GK-250E | GK-320E | GK-420E | GK-580E |
Total Volume of Mixer (L) | 47 | 87 | 195 | 250 | 320 | 450 | 580 |
Fill factor | 0.65 | 0.65 | 0.65 | 0.65 | 0.65 | 0.7 | 0.65 |
Rotor speed (r/min) plastsea | 10-60 | 10-60 | 10-60 | 10-60 | 10-60 | 10-60 | 10-45 10-60 |
Ram Pressure (Mpa) | 0.5 | 0.55 | 0.54 0.58(Hyd.) | 0.51 | 0.62 | 0.55 | 0.55 |
Max production capacity (t/h) Plastea | 0.72 | 1.36 | 3.04 | 3.9 | 5 | 7.5 | 10.4 |
Compressed air pressure (Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
|
|
Air consumption (m3/h) | 92 | 140 | 432 | 423 | 604 | plastsea |
|
Cooling water pressure (Mpa) | 0.2-0.4 | ||||||
Cooling water consumption of main machine (m3/h) | 20 | 25 | 40/50 | 50 | 60 | 60 | 70 |
Steam pressure (Mpa) | 0.3 |
| 0.3 | ||||
Power of main motor (KW) | 280 | 520 | 1100 | 1320 | 1680 | 2x1250 | 2x1250 2x1250 |
Overall size(without motor) m | 3.9x2.4x3.7 | 4.6x2.3x4 | 5.9x3.4x5.6 | 6.1x4x6.1 | 6.6x4.6x6.5 | 6.7x4.6x6.3 | 7.5x4.8x7.5 |
Weight (without motor and gearbox) T | 8.5 | 11 | 26.5 | 33 | 38 | 50 | 60 |
|
|
|
|
|
|
|
|
Above parameter is only part. If you need more parameters and size of our rubber mixer, please contact us!
Our Services :
1. We will design,manufacture,install and test the machines according to customers' requirement .Relevant personnel training for customers,ensure that customers fully grasp the using method and maintenance of technology.
2 .Our service department listen to customers' feedback at any time and provide spare parts timely.
Guarantee and after-sale service
one year guarantee for whole machine
24 hours technical support by email or call
calling or door-to-door service
As a professional machinery supplier,Plastsea Corp. was established by an experienced and professional team.It's located in Qingdao city which is the rubber&plastic industry center of China with the top level institute and university .
After several years developing,Plastsea has offered its excellent service and products to more than 30 countries in the world.
At present ,Plastsea focuses on Rubber and Tyre industries.Through joint-venture and cooperation methos,Plastsea has developed eight fabrication bases in China.The products cover internal mixer,twin-screw sheer,batch off cooling molds,tyre building drum,tyre bladder,tyre bladder mold,etc.
Based on the ideas of High quality and credit, we strictly control the quality of the products, and constantly improve our powerful technical support and personnel training to per customers. Mutual benefit is our aim and customers' satisfaction is our success.
