Specifications
p16 outdoor led display moduleP16 rgb module Size:256*256MM
Resolution:16*16dots
Density:3906dots/sqm
p16 outdoor led display module
Technical Specification | |
Pixel pitch |
16mm |
Pixel configuration |
1R1G1B |
Pixel resolution |
3906 dot/m2 |
Cabinet size |
768mm x 768mm |
Cabinet resolution |
60 x60 |
Module size |
256mm x 256mm |
Weight (KG/cabinet) |
40kg |
Max Power |
<700 W/m2 |
Ave Power |
350 W/m2 |
Brightness |
>8000 cd/m2 |
Grey color |
16.7M |
Refresh frequency |
>3000HZ |
Frame rate |
>60HZ |
The best viewing distance |
5-50m |
Viewing angle |
H100°/ V50° |
Operation temperature |
-40°C-55°C |
Related humidity |
10%~95% |
Drive method |
static constant current |
Brightness adjustment |
0~100% stepless |
Scotoma rate |
<0.0001 |
MTTF |
>5000H |
Lifespan |
100000H |
Computer operation system |
Win98/Win XP/Win 2000 |
Visual signal |
RF, S-Video,RGB,RGBHV,YUV,YC,etc. |
Control method |
to be synchronized with computer |
Ingress protection |
IP65 |
Professional LED screens& LED Displays Module Manufacturer
-----SMD: p3/p4/p5/p6/p7.62/p10 indoor full color led module and led display.
-----Single Color:P10 red outdoor/P10 White outdoor/P10 Blue outdoor/P10 Green outdoor/P10 Yellow outdoor&SIMI-outdoor led module and led screen
-----Double Color:P10 double color/p16 double color/p20 double color SIMI-outdoor&outdoor led module and led screen
-----all of our led module has highly resolution, good image effect,and easy to install and convenient to carry;
----- Resonable price,good uniformity, stable capability and high brightness;
-----Aluminum alloy material both for fixed installation and hanging rental;
-----Own Unique Design LED Screen
