Specifications
1 Dc12v Motherboard China Supplier Certifications CE ISO90012 adopts MSTAR program,
3 support 3 HDMI/MPEG
4L-type port
Dc12v Motherboard China Supplier
adopts MSTAR program,;support 3 HDMI/MPEG; USB media play;L-type port design
GENERAL DESCRIPTION
The TV board is suitable for worldwide analog TV system PAL/the NTST/the SECAM, Which is compatible with LCD board in market mainstream manufactures, such as SAMSUNG, CMO , AU , LGP , SHARP, , BOE and so on, It can reappear picture color and sound in real world .Key IC adopt MSTAR single chip mMST6M182 program
1 TV system support PAL+SECAM/NTSC system, optional full standard system
Max supports FULL HD 1920X1200 resolution TFT-LCD screen
2 support for the polarized / shutter 3D screen
L-type port design , including 2 AV input , one VGA port supports 1920X1080 @ 60Hz input
3 two analog high-definition port signal ( YPbPr ) input, maximum support 1080P format
4 three-way high-definition digital multimedia port ( HDMI ) 1.3A , HDCP1.2 and DVI 1.0
5 USB port, supports Audio(MP3 WMA),Video (AVI RM RMVB MPEG1~4,H.264),Picture(JPEG BMP PNG),Text file(TXT)
6 Dynamically adjust picture's color , contrast ratio, definition and so on.
Brightness, chroma instantaneous improvement function , black / white level extensions function , color compensation function
7 3D video decoding ( PAL / NTSC ) , brightness separation , spatial noise reduction function
8 Supports control of treble or bass ,Stereo input.
Rating of Audio loudspeaker output is 10w*2(8ohm)
9 Automatically detect input video format.
10 Imitation WINDOWS XP interface OSD ,Humanization operating menu.
11 Reliable EMC and treatment measure of anti-static.
12 Built-in large power input, can choose single 12V DC power input.
Package : use plastic and carton to pack the boad
INVERTER AND POWER BOARD
