Universal Tv Motherboard Board Tv Certifications CE ISO9001

Universal Tv Motherboard Board Tv Certifications CE ISO9001 thumbnail-1
Universal Tv Motherboard Board Tv Certifications CE ISO9001 photo-1
US$ 14 - 16 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
CND
Model Number:
HD6M182-LL
Type:
LCD
Contact Supplier Request Quote Chat Now
CND Electronic Technology (Shenzhen) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CND
Model Number HD6M182-LL
Type LCD
Backlight Type LED
Wide Screen Support Yes
Display Format 1080P (Full-HD)
Use Hotel TV
Place of Origin Guangdong, China

Specifications

1 Universal Tv Motherboard Board Tv Certifications CE ISO9001
2 adopts MSTAR program,
3 support 3 HDMI/MPEG
4L-type port

  Universal Tv Motherboard Board Tv Certifications CE ISO9001
 adopts MSTAR program,;support 3 HDMI/MPEG; USB media play;L-type port design

GENERAL DESCRIPTION

The TV board is suitable for worldwide analog TV system PAL/the NTST/the SECAM, Which is compatible with LCD board in market mainstream manufactures, such as SAMSUNG, CMO , AU , LGP , SHARP, , BOE and so on, It can reappear picture color and sound in real world .Key IC adopt MSTAR single chip mMST6M182 program

1 TV system support PAL+SECAM/NTSC system, optional full standard system

Max supports FULL HD 1920X1200 resolution TFT-LCD screen

2 support for the polarized / shutter 3D screen

L-type port design , including 2 AV input , one VGA port supports 1920X1080 @ 60Hz input

3 two analog high-definition port signal ( YPbPr ) input, maximum support 1080P format

4 three-way high-definition digital multimedia port ( HDMI ) 1.3A , HDCP1.2 and DVI 1.0

5 USB port, supports Audio(MP3 WMA),Video (AVI RM RMVB MPEG1~4,H.264),Picture(JPEG BMP PNG),Text file(TXT)

6 Dynamically adjust picture's color , contrast ratio, definition and so on.

Brightness, chroma instantaneous improvement function , black / white level extensions function , color compensation function

7 3D video decoding ( PAL / NTSC ) , brightness separation , spatial noise reduction function

8 Supports control of treble or bass ,Stereo input.

Rating of Audio loudspeaker output is 10w*2(8ohm)

9 Automatically detect input video format.

10 Imitation WINDOWS XP interface OSD ,Humanization operating menu.

11 Reliable EMC and treatment measure of anti-static.

12 Built-in large power input, can choose single 12V DC power input.

Universal Tv Motherboard Board Tv Certifications CE ISO9001Universal Tv Motherboard Board Tv Certifications CE ISO9001

Package  :  use plastic and carton to pack the boad

Universal Tv Motherboard Board Tv Certifications CE ISO9001Universal Tv Motherboard Board Tv Certifications CE ISO9001Universal Tv Motherboard Board Tv Certifications CE ISO9001
