Hot Melt Adhesive Machine, Hot Melt Glue Machine, Coating Machine
- XIAMEN PORT CHINA
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | YONGTAI MACHINE | |
| Model Number | YT-SP202 |
Product Description
Specifications
1.safe,convient to work,improve the efficiency.2.Spot spraying, strip spraying, Mist spraying or scraper nozzle gluing
Main characteristics hot melt machine
1. The surface of melting jar is coated with Teflon in order to prevent from carbonization and reduce jam.
2. Double shower nozzle, obviously improve work efficiency.
3. This hot melt coating machine adopts intelligent PID temperature control system with ulta-temperature protection and time-lapse spraying function.
4. Spraying mouth can be replaced with application.There's punctate, strip, reticular,etc..
5. Foot plate type controlling switch,convenient to all operations.
SPECIFICATION:
ITEM | UNIT | YT-SP202 | YT-DP201 | YT-QB202 | YT-QB201 |
Tank Capacity | KG | 3.0 | 3.0 | 5. 0 | 5.0 |
Max. malting rate | KGHOUR | 5.0 | 5.0 | 7.0 | 7.0 |
Max. Operation temp. | °C | 200 | 200 | 200 | 200 |
Melt Power | Watt | 2060 | 1600 | 2160 | 2160 |
Motor Power | Watt | 60 | 60 |
|
|
Air pressure | KGCM² | 4-6 | 4-6 | 4-6 | 4-6 |
Demension(L*W*H) | MM | 420*380*640 | 420*380*640 | 575*740*640 | 575*535*640 |
Weight | KG | 32 | 30 | 35 | 34 |
Max. Viscosity | Cps | 100,000 | 100,000 | 120,000 | 120,000 |
Gun Qty. |
| 2 | 1 | 2 | 1 |
Power Requirement | Single Phase (1Φ), 220 V | ||||
Pump Type |
| Gear pump | Gear pump | Piston pump | Piston pump |
