Home > Products > floor deck roll forming machine > Dixin Decking Floor Production Roll Forming Line /high Quality Deck Floor Machine
Dixin Decking Floor Production Roll Forming Line /high Quality Deck Floor Machine
- tianjin
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
Long-Span Forming Machine With Curving Machine
-
DX 720 Floor Deck Roll Forming Machine FOR Nigeria
-
DX 720 Floor Deck Roll Forming Machine/Building Raw Materials
-
DX 720 Floor Deck Roll Forming Machine/floor Panel Making Machine
-
Novel Design of DX 720 Floor Deck Roll Forming Machine
-
China Suppliers Steel Floor Decking Roll Forming Machine on Sale
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Steel | Use | Floor | |
| Production Capacity | 8-12m/min | Brand Name | DIXIN | |
| Model Number | decking machine | Power(W) | 27.5kw | |
| Voltage | 380V | Dimension(L*W*H) | 6800mm*800mm*1200mm | |
| Weight | 7.2 tons | Certification | ISO9001 | |
| Warranty | One Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Dixin Decking floor production roll forming line /high quality deck floor machine
Steel floor deck sheet is rolled by steel floor decking roll forming machine,the finished product are of many features,such as simple shape,large wave height,high intensity and good adhesiveness when pouring the concrete together with the welded steel wire net on-site,in the high story building,it not only can save steel mould board,but also reduce the bearing of the floor: on basis of equal capacity,it reduces the steel amount of engineering useage,so that it saves cost of investment.
The steel floor deck roll foming machine consists of uncoiler and its base,infeed guides,fixed position driven forming stations,shearing device,hydraulic station,PLC control console and so on. Our company has dozens of profile models for this series roll forming machine. We can design different kinds of profile and fitting for steel deck machine,as per customers’ requirements.
Component
NO. | Item | Unit | Qty |
1 | Manual decoiler | set | 1 |
2 | Main roll forming machine | set | 1 |
3 | PLC control box | set | 1 |
4 | Supporter table | set | 1 |
Workflow
Decoiler--Roll Forming--PLC System--Hydraulic System--Cutting--Output Table
Material thickness: 0.8---1.2mm
Material hardness: 195 mpa---350 mpa
Material width: 1250mm
Formed width: 914mm
Wavelength: 305 mm
Step height: 75mm
Step length:150mm---380mm(adjustable)
Forming speed: 8-10m/min
