1*8 ABS box optical fiber PLC splitter
- 1000 Piece / Pieces per Month
- qingdao
- T/T L/C D/P D/A Credit Card
- RF Testing Wire Cable Assembly SMA Male Female connector
- 50 Watt Dummy Load/Termination Low PIM3 -150dBc N male/female
- high power good PIM -150dBc RF Coaxial Fixed Dummy Load/Termination 200W
- good low PIM3 -150dBc RF Coaxial Fixed Dummy Load/Termination 50W
- 800-2500MHz 3x2 3 in 2 out Hybrid Combiner n female type DC-3Ghz
- RF 800-2700MHz 2 in 1 out 2x1 3dB Hybrid Coupler Combiner N Female type
Product Details
Place of Origin: | Shandong, China | Brand Name: | APT | Model Number: | SM |
Product Description
1.Product Introduction
Planar lightwave circuit (PLC) splitter is fabricated using silica optical waveguide technology. It features wide operating wavelength range, good channel-to-channel uniformity, high reliability and small size, and is widely used in PON networks to realize optical signal power management.
Cassette-type PLC splitter put PLC splitter chip and input/output array packaged in a samll box,which derivtived by fiber diameter up to 2mm or 3mm.fiber can be used for welding,can also be processing various types of optical fiber connectors.
Qingdao APT provides a whole series of 1xN and 2xN splitters that are tailored for specific applications. All products meet YD/T1117-2001 All optical fiber branching device technical conditions ,YD-T 2000-209 PLC Integrated optical devices PLC optical power splitter>> etc, and are certified by TLC for network deployment.
2.Specifications
1*2,1*4,1*8,1*16,1*32,1*64(with/without connectors)
2*2,2*4,2*8,2*16,2*32,2*64(with/without connectors)
3. Performance and Technical parameters
Technical data | Specification(without connector loss) | |||||||
work wavelength (nm) | 1260-1650 | |||||||
type | 1*4 | 1*8 | 1*16 | 1*32 | 2*4 | 2*8 | 2*16 | 2*32 |
Insertion loss (dB) | ≤7.3 | ≤10.5 | ≤13.5 | ≤17.0 | ≤7.6 | ≤11.0 | ≤14.5 | ≤17.5 |
Uniformity (dB) | ≤0.6 | ≤0.8 | ≤1.2 | ≤1.5 | ≤0.8 | ≤1.5 | ≤1.5 | ≤2.0 |
PDL(dB) | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.2 | ≤0.4 | ≤0.4 | ≤0.4 |
Return loss (dB) | >50 | directivity(dB) | >55 | |||||
Work temperature (℃) | -40-+85 | storage temperature (℃) | -40-+85 |
duct size(mm)
type | 1*2 | 1*4 | 1*8 | 1*16 | 1*32 |
L×W×H | 100×80×9 | 100×80×9 | 100×80×9 | 120×80×18 | 140×114×18 |
type | 2*2 | 2*4 | 2*8 | 2*16 | 2*32 |
L×W×H | 100×80×9 | 100×80×9 | 100×80×9 | 120×80×18 | 140×114×18 |
5.ordering information
product name | bare PLC splitter |
specification | 1*2,1*4,1*8,1*16,1*32,( with/without connectors) |
2*2,2*4,2*8,2*16,2*32,( with/without connectors) | |
quantity | user-defined |
