Ship Truck Loader Unloader Rice Grain Pneumatic Air Conveyor

Name: Ship Truck Loader Unloader Rice Grain Pneumatic Air Conveyor
Brand: DOUBLE BIRDS
SKU: 133955075

US$ 3,000 - 6,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Gravity Conveyor

Material:

Other, Carbon steel

Zhengzhou Double Birds Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Gravity Conveyor

Material Other, Carbon steel

Material Feature Heat Resistant

Structure Conveyor System

Place of Origin Henan, China

Brand Name DOUBLE BIRDS

Model Number DB-10

Voltage 220/320V

Power(W) 11.75KW

Dimension(L*W*H) 1780*1058*1550

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

ship truck loader unloader rice grain pneumatic air conveyor

Technical parameters

Machine Model	DB-3	DB-5	DB-10	DB-15	DB-20C	DB-30C
Convey measure (t/h)	3	5	10	15	20	30
Power of Air Blower (KW)	5.5-6	7.5-8	11-11.5	15-15.5	22-23	37
Power of Close the wind machine(KW)	0.75	0.75	0.75	1.1	1.1	1.5
Total power(KW)	6.25	8.25	11.75	16.1	23.1	38.5
Air Pressure (water column/mm)	940	1000	1500	1600	2200	3300
Air mass flow(m3/H)	780	800	1000	1600	1800	1800
Airflow velocity(m/s)	26	24	24	25	25	25
Feed pipe diameter(mm)	124	124	150	150	160	160
Pipe diameter (mm)	70	100	124	150	160	160
Horizontal maximum transmission distance(m)	20	30	50	70	120	70
Maximum distance(m)	6.8	8.5	10	20	30	50
Max.lift head (m)	5	5	8	12	18	30
Total weight(KG)	400	415	460	530	600	900
Dimension (length * width * height) mm	17801050 1550	17801058 1550	17801058 1550	20801148 1800	23201320 2720	23801600 2720
