Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Solar Power Cable / VDE/UL Certified Cable
Solar Power Cable / VDE/UL Certified Cable
US$ 4.86 - 4.89
MOQ: 3000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Haerkn
Model Number:
PV1-F 35mm2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
VDE H05S-K High Temperature Silicone WireUS$ 0.1 - 5MOQ: 6100 Meters -
Flexible PVC Parallel Wire UL 2800US$ 0.03 - 6MOQ: 6100 Meters
-
Solar PV Cable / VDE TUV Certified DC Solar CableUS$ 4.86 - 4.89MOQ: 3000 Meters
-
Solar Cable / UL Certified 16AWGUS$ 0.98 - 1.12MOQ: 5000 Meters
-
Solar Cable / UL Certified 20AWGUS$ 0.98 - 1.12MOQ: 5000 Meters
Place of Origin
Guangdong, China
Brand Name
Haerkn
Model Number
PV1-F 35mm2
Type
Other, double insulated
Application
Other, Connection wiring for solar PV power system and PV inverter, and so on
Conductor Material
Other, Tinned copper
Conductor Type
Stranded
Insulation Material
Other, XLPE white, XLPE black
Specifications
Solar PV Cable1. VDE certified & ROHS compliant
2. teflo double insulated
3. 0.6/1KV & -40~+90 deg C
4. Tinned copper
PV1-F 35mm2 Specification
- Rated temperatur: 90°C
- Max. temperature: 120°C
- Rated Voltage: 0.6 ~ 1.0 kv
- Color: Inner white outer black
- Conductor: Tinned copper 266/0.40 stranded 8.54±0.25mm
- Inner Insulation: XLPE white, thickness: 0.66~0.93mm
- Inner Dia.: 10.4±0.3mm
- Outer Insulation: XLPE black, thickness: 0.50~0.70mm
- Outer Dia.: 11.8±0.4mm
- Application: Connection wiring for solar PV power system and PV inverter, and also can be used as underground feeder cable.
- Reference Standard: TUV 2 Pfg 1169/08.2007
Electrical Characteristics:
- Max DC Conductor Resistance at 20°C (Ω/km): 0.565
- Min. Insulation DC Resistance(Mohm.km): 10.0
- Dielectric Strength(KV/min): AC6.5/DC15
Mechanical Characteristics:
Test Object: Insulation
- Test Material: XLPE
- Before Tensile Strength (N/mm2) ≥6.5
- Aging Elongation (%) ≥125
- Aging Condition (°C) 150±2°C×168H
- After Tensile Strength (N/mm2) ≥70% of original
- Aging Elongation (%) ≥70% of original
Test Object: Jacket
- Test Material: XLPE
- Before Tensile Strength (N/mm2) ≥8.0
- Aging Elongation (%) ≥125
- Aging Condition (°C) 150±2°C×168H
- After Tensile Strength (N/mm2) ≥70% of original
- Aging Elongation (%) ≥70% of original
