Silicone Heat Resistant Wire UL 3512 Silicone Wire
US$ 0.02 - 0.8
MOQ: 6100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Haerkn
Model Number:
UL 3512
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
H05S-K Heat Resistance Silicone Power CableUS$ 0.06 - 0.8MOQ: 6100 Meters -
Special Braided CableUS$ 0.01 - 5MOQ: 6100 Meters
-
UL 3668 Heater Element WireUS$ 0.01 - 5MOQ: 6100 Meters
-
UL 3586 Silicone Coated CableUS$ 0.01 - 5MOQ: 6100 Meters
-
High Temperature Silicone Insulation Cables UL3536US$ 0.01 - 5MOQ: 6100 Meters
Place of Origin
Guangdong, China
Brand Name
Haerkn
Model Number
UL 3512
Type
Insulated
Application
Heating
Conductor Material
Other, tin, nickel or silver coated
Conductor Type
Other, solid or stranded
Insulation Material
Other, SR-Silicone
Specifications
Silicone Heat Resistant Wire UL 3512 Silicone Wire1.Rated Voltage:600V
2.Rated Temperature:200degC
3.Insulation:SR-silicone
Silicone Heat Resistant Wire UL 3512 Silicone Wire
1.Rated voltage: 600V
2.Rated temperature:200deg C
3.Conductor : 0.3 - 250 sq mm
4.Conductor material: tin, nickel or silver coated (solid or strand copper)
5.Insulation material:SR- Silicone
6.Color: Same as clients' required
| Style 3512 | Insulated Wire | |
| Rating | 200 deg C, 600 Vac, Horizontal flame. |
| Conductor | 0.3 - 250 sq mm solid or stranded copper (tin, nickel or silver coated). If tinned copper strands are used, they shall be 0.0152 in diameter or larger. |
| Insulation | SR - SILICONE |
| 0.3-4.0 sq mm conductor size | 30 mils min average | 27 mils minimum at any point |
| 4.1-9.0 sq mm | 45 avg | 40 min |
| 9.1-35.0 sq mm | 60 avg | 54 min |
| 35.1-100.0 sq mm | 80 avg | 76 min |
| 100.1-250.0 sq mm | 95 avg | 85 min |
Maybe applied in two layers with an intermediate glass braid (optional).
| Standard | Appliance Wiring Material UL 758. |
| Marking | General. |
| Use | Internal wiring of appliances where totally enclosed. |
